ASRock X370 Pro BTC+ [12/76] English
![ASRock X370 Pro BTC+ [12/76] English](/views2/1690520/page12/bgc.png)
X370 Pro BTC+
7
English
No. Description
1 ATX 12V Power Connector (ATX12V2)
2 ATX 12V Power Connector (ATX12V1)
3 Chassis Fan Connector (CHA_FAN1)
4 CPU Fan Connector (CPU_FAN1)
5 288-pin DDR4 DIMM Slot (DDR4_A2)
6 Reset Button (RSTBTN1)
7 Power Button (PWRBTN1)
8 USB 2.0 Header (USB_3_4)
9 Chassis Fan Connector (CHA_FAN2)
10 ATX Power Connector (ATXPWR2)
11 Power LED and Speaker Header (SPK_PLED1)
12 ATX Power Connector (ATXPWR1)
13 System Panel Header (PANEL1)
14 SATA3 Connector (SATA3_1)
15 Mining Port (M_Port1)
16 PCIe Power Connector (PWR_PCIE3)
17 Mining Port (M_Port2)
18 Chassis Fan Connector (CHA_FAN3)
19 PCIe Power Connector (PWR_PCIE4)
20 Mining Port (M_Port3)
21 PCIe Power Connector (PWR_PCIE5)
22 Mining Port (M_Port4)
23 Chassis Fan Connector (CHA_FAN5)
24 PCIe Power Connector (PWR_PCIE6)
25 Mining Port (M_Port5)
26 ATX Power Connector (ATXPWR3)
27 PCIe Power Connector (PWR_PCIE7)
28 Mining Port (M_Port6)
29 PCIe Power Connector (PWR_PCIE8)
30 Chassis Fan Connector (CHA_FAN7)
31 Chassis Fan Connector (CHA_FAN8)
32 TPM Header (TPMS1)
33 Chassis Fan Connector (CHA_FAN6)
