MECHANICAL SPECIFICATION
178.5~240W Constant Current Mode LED Driver
ELG-240-C series
CASE NO.: 262A Unit:mm
※ Blank-Type
: Max. Case Temperature
※ A-Type
tc
: Max. Case Temperature
tc
233
244
220
300±20
300±20
53.8
71
37.5
37
AC/L(Brown)
AC/N(Blue)
4- 4.5ψ
233
244
220
300±20
300±20
37.5
37
AC/L(Brown)
AC/N(Blue)
41.75
19
53.8
71
4- 4.5ψ
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
tc
79
32
tc
79
32
Vo+(Brown)
Vo-(Blue)
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&H05RN-F 1.0mm
2
Vo+(Brown)
Vo-(Blue)
File Name:ELG-240-C-SPEC 2018-09-30
