ASRock 890FX Deluxe5 Инструкция онлайн [23/64] 538921
![ASRock 890FX Deluxe5 Инструкция онлайн [23/64] 538921](/views2/1691319/page23/bg17.png)
2323
2323
23
CrossFire
TM
Bridge
Step 5. Connect the DVI monitor cable to the DVI connector on the Radeon graphics
card on PCIE2 slot. (You may use the DVI to D-Sub adapter to convert the
DVI connector to D-Sub interface, and then connect the D-Sub monitor
cable to the DVI to D-Sub adapter.)
