46
3.4.7 Super IO Configuration
OnBoard Floppy Controller
Use this item to enable or disable fl oppy drive controller.
Serial Port
Use this item to enable or disable the onboard serial port.
Serial Port Address
Use this item to set the address for the onboard serial port. Confi guration
options: [3F8h / IRQ4] and [3E8h / IRQ4].
Infrared Port
Use this item to enable or disable the onboard infrared port.
Infrared Port Address
Use this item to set the address for the onboard infrared port.Confi guration
options: [2F8h / IRQ3] and [2E8h / IRQ3].
BIOS SETUP UTILITY
Configure Super IO Chipset
Allow BIOS to Enable
or Disable Floppy
Controller.
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985
-
2003, American Megatrends, Inc.
Advanced
OnBoard Floppy Controller
Serial Port Address
Infrared Port Address
[Disabled]
[3F8 / IRQ4]
[Disabled]
