3838
3838
38
3.1.23.1.2
3.1.23.1.2
3.1.2
Navigation KeysNavigation Keys
Navigation KeysNavigation Keys
Navigation Keys
Please check the following table for the function description of each navigation
key.
Navigation Key(s) Function Description
/ Moves cursor left or right to select Screens
/ Moves cursor up or down to select items
+ / - To change option for the selected items
<Enter> To bring up the selected screen
<F1> To display the General Help Screen
<F9> To load optimal default values for all the settings
<F10> To save changes and exit the UEFI SETUP UTILITY
<ESC> To jump to the Exit Screen or exit the current screen
3.23.2
3.23.2
3.2
Main ScreenMain Screen
Main ScreenMain Screen
Main Screen
When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the
system overview.
System Time [Hour:Minute:Second]
Use this item to specify the system time.
System Date [Day Month/Date/Year]
Use this item to specify the system date.
