MEAN WELL ELGT-150-C1050DA Data Sheet онлайн
File Name:ELGT-150-C-SPEC 2018-09-30
ELGT-150-Cseries
■ Features ■ Applications
■ Model Encoding
- C700ELGT
-
150
A
Rated wattage
Series name
■ Description
ELGT-150-C series is a 105~150W LED AC/DC class driver featuring the constant current mode andⅡ
high voltage output. ELGT-150-C operates from 100~305VAC and offers models with different
rated current ranging between 700mA and 1400mA. Thanks to the high efficiency up to 92%,
with the fanless design, the entire series is able to operate for -40 ~+90 case temperature under℃℃
free air convection. The design of metal housing and IP67/IP65 ingress protection level allows
this series to fit both indoor and outdoor applications. ELGT-150-C is equipped with various function
options, such as dimming methodologies, so as to provide the optimal design flexibility for LED
lighting system.
Metal housing design with functional Ground
design
Class Ⅱ
Constant Current mode output
Built-in active PFC function
<0.5W
No load / Standby power consumption
IP67 / IP65 rating for indoor or outdoor installations
Function options: output adjustable via potentiometer;
3 in 1 dimming (dim-to-off); Smart timer dimming; DAL
I;
Typical lifetime>50000 hours
5 years warranty
LED street lighting
LED harbor lighting
LED bay lighting
LED greenhouse lighting
LED flood lighting
Comply with
class applicationⅡ
Function options
Type
Blank
A
B
IP Level
IP67
IP65
IP67
Io fixed.
Io adjustable through built-in potentiometer.
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
Function Note
In Stock
In Stock
In Stock
Rated output current (700/1050/1400mA)
DA
IP67 DALI control technology. In Stock
MM
110
IP67
IP65
(for DA-Type only)
D2 IP67 Built-in Smart timer dimming and programmable function. In Stock
105~150W Class Constant Current Mode LED DriverⅡ
AB IP65
Io adjustable through built-in potentiometer&
In Stock
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
