![ASRock N68-S3 UCC — настройка BIOS: управление частотой и разгон процессора [32/53]](/img/pdf.png)
ASRock N68-S3 UCC — настройка BIOS: управление частотой и разгон процессора [32/53]
Превью страниц
Страница 32 /
53
![ASRock N68-S3 UCC [32/53] Oc tweaker](/views2/1691901/page32/bg20.png)
3232
3232
32
BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
Overclocking may cause
damage to your CPU and
motherboard.
It should be done at
your own risk and
expense.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
CPU Configuration
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
Boot Failure Guard
CPU/LDT
Spread Spectrum
SATA Spread Spectrum
Spread Spectrum
PCIE
Processor Maximum Frequency
North Bridge
Processor Maximum Voltage
Maximum Frequency
x15.0 3000 MHZ
1.4250 V
x10.0 2000 MHZ
[Enabled]
[Enabled]
[Enabled]
[Enabled]
Multiplier/Voltage Change
HT Bus Speed
HT Bus Width
Unlock CPU Core
[Auto]
[Auto]
[Auto]
[Disabled]
3.33.3
3.33.3
3.3
OC TOC T
OC TOC T
OC T
weakweak
weakweak
weak
er Screener Screen
er Screener Screen
er Screen
In the OC Tweaker screen, you can set up overclocking features.
CPU Configuration
Overclock Mode
Use this to select Overclock Mode. The default value is [Auto]. Configura-
tion options: [Auto], [CPU, PCIE, Sync.], [CPU, PCIE, Async.] and [Optimized].
CPU Frequency (MHz)
Use this option to adjust CPU frequency.
PCIE Frequency (MHz)
Use this option to adjust PCIE frequency.
Boot Failure Guard
Enable or disable the feature of Boot Failure Guard.
CPU/LDT Spread Spectrum
This feature will be set to [Enabled] as default. Configuration options:
[Disabled] and [Enabled].
PCIE Spread Spectrum
This feature will be set to [Enabled] as default. Configuration options:
[Disabled] and [Enabled].
SATA Spread Spectrum
This feature will be set to [Enabled] as default. Configuration options:
[Disabled] and [Enabled].
Processor Maximum Frequency
It will display Processor Maximum Frequency for reference.
North Bridge Maximum Frequency
It will display North Bridge Maximum Frequency for reference.
Processor Maximum Voltage
It will display Processor Maximum Voltage for reference.
