4545
4545
45
BIOS SETUP UTILITY
Main
H/W Monitor Boot Security Exit
Advanced Settings
WARNING : Setting wrong values in below sections
may cause system to malfunction.
Options for CPU
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
CPU Configuration
Chipset Configuration
ACPI Configuration
IDE Configuration
PCIPnP Configuration
Floppy Configuration
SuperIO
USB Configuration
Configuration
3.33.3
3.33.3
3.3
Advanced ScreenAdvanced Screen
Advanced ScreenAdvanced Screen
Advanced Screen
In this section, you may set the configurations for the following items: CPU
Configuration, Chipset Configuration, ACPI Configuration, IDE Configuration, PCIPnP
Configuration, Floppy Configuration, SuperIO Configuration, and USB Configuration.
Setting wrong values in this section may cause
the system to malfunction.
K10N78hSLI-1394
System Time [Hour:Minute:Second]
Use this item to specify the system time.
System Date [Day Month/Date/Year]
Use this item to specify the system date.
BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
System Overview
System Time
System Date
[ :00:09]
[Tue 04/81/2008]
Use [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Time.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
BIOS Version
Processor Type
Processor Speed
Microcode Update
L1 Cache Size
L2 Cache Size
Total Memory
DDRII1
DDRII2
L3 Cache Size
DDRII3
DDRII4
: K10N78hSLI-1394 P1.0
: AMD Athlon(tm) 9650 Quad-Core
Processor (64bit)
: 2300MHz
: 100F23/1000065
: 512KB
: 2048KB
: 2048KB
: 2048MB with 256MB shared memory
Dual-Channel Memory Mode
: 1024MB/400MHz (DDRII 800)
: 1024MB/400MHz (DDRII 800)
: None
: None
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
