1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
NVIDIA
GeForce
7025 /
nForce
630a
FSB800
DDRII_1 (64 bit, 240-pin module)
DDRII_2 (64 bit, 240-pin module)
IDE1
SATAII_1
SATAII_2 SATAII_4
(PORT 0.0)
(PORT 0.1) (PORT 1.1)
SATAII_3
(PORT 1.0)
CHA_FAN1
SPEAKER1
1
HDLED RESET
PLED PWRBTN
1
PANEL1
11
ATXPWR1
4Mb
BIOS
CMOS
BATTERY
1
CLRCMOS1
CPU_FAN1
ATX12V1
PS2_USB_PW1
1
20.8cm (8.2-in)
24.4cm (9.6-in)
1
USB4_5
SOCKET AM2
FSB800
DDRII_3 (64 bit, 240-pin module)
DDRII_4 (64 bit, 240-pin module)
1
USB6_7
1
USB8_9
HD_AUDIO1
1
FLOPPY1
CD1
COM1
1
LAN
PHY
AUDIO
CODEC
Super
I/O
N68-GE
PCIE1
PCIE2
PCI1
PCI2
Top:
SIDE SPK
Center:
REAR SPK
Bottom:
SPDIF_01
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
USB 2.0
T: US B0
B: USB1
Top:
RJ-45
USB 2.0
T: U SB 2
B: USB3
PARALLEL PORT
VGA1
PS2
Mouse
PS2
Keyboard
PWR_FAN1
Phenom II
AM2+/AM3
DDR2 1200
Dual Channel
EuP Ready
RoHS
Gigabit LAN
1
24
3
6
7
5
8
9
10
11
12
13
14
15
16
17
18
1920
21
22
23
24
25
26
27
28
29
30
1 PS2_USB_PW1 Jumper 16 USB 2.0 Header (USB6_7, Blue)
2 ATX 12V Power Connector (ATX12V1) 17 USB 2.0 Header (USB4_5, Blue)
3 CPU Heatsink Retention Module 18 Chassis Speaker Header
4 AM2 940-Pin CPU Socket (SPEAKER 1, Purple)
5 CPU Fan Connector (CPU_FAN1) 19 System Panel Header (PANEL1, Orange)
6 2 x 240-pin DDR2 DIMM Slots 20 Chassis Fan Connector (CHA_FAN1)
(Dual Channel A: DDRII_1, DDRII_2; Yellow) 21 Clear CMOS Jumper (CLRCMOS1)
7 2 x 240-pin DDR2 DIMM Slots 22 Floppy Connector (FLOPPY1)
(Dual Channel B: DDRII_3, DDRII_4; Orange) 23 Serial Port Connector (COM1)
8 ATX Power Connector (ATXPWR1) 24 Power Fan Connector (PWR_FAN1)
9 Primary IDE Connector (IDE1, Blue) 25 Internal Audio Connector: CD1 (Black)
10 Primary SATAII Connector (SATAII_1 (PORT 0.0)) 26 Front Panel Audio Header
11 Third SATAII Connector (SATAII_3 (PORT 1.0)) (HD_AUDIO1, Lime)
12 Fourth SATAII Connector (SATAII_4 (PORT 1.1)) 27 PCI Slots (PCI1- 2)
13 Secondary SATAII Connector 28 PCI Express x16 Slot (PCIE2)
(SATAII_2 (PORT 0.1)) 29 PCI Express x1 Slot (PCIE1)
14 SPI Flash Memory (4Mb) 30 NVIDIA GeForce 7025 / nForce 630a
15 USB 2.0 Header (USB8_9, Blue)
