![ASRock AM1B-ITX [14/60] English](/views2/1692093/page14/bge.png)
English
10
No. Description
1 Power Fan Connector (PWR_FAN1)
2 Clear CMOS Jumper (CLRCMOS1)
3 CPU Fan Connector (CPU_FAN1)
4 Chassis Intrusion Header (CI1)
5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_A2)
6 ATX Power Connector (ATXPWR1)
7 Chassis Speaker Header (SPEAKER1)
8 System Panel Header (PANEL1)
9 SATA3 Connector (SATA3_1)
10 SATA3 Connector (SATA3_2)
11 SATA3 Connector (SATA3_A2)
12 SATA3 Connector (SATA3_A1)
13 Chassis Fan Connector (CHA_FAN1)
14 USB 3.0 Header (USB3_2_3)
15 TPM Header (TPMS1)
16 COM Port Header (COM1)
17 USB 2.0 Header (USB4_5)
18 USB 2.0 Header (USB6_7)
19 Front Panel Audio Header (HD_AUDIO1)
