1.4 Motherboard Layout1.4 Motherboard Layout
1.4 Motherboard Layout1.4 Motherboard Layout
1.4 Motherboard Layout
Super
I/O
PCI
EXPRESS
USB2.0
CMOS
BATTERY
ATXPWR1
SOCKET
A
M2
ALiveSATA2-GLAN
CD1
VIA
K8T890 CF
Chipset
VIA
VT8237A
Chipset
ATX12V1
PS2_USB_PWR1
1
USB 2.0
T: USB2
B: USB3
PARALLEL PORT
COM1
PS2
Mouse
PS2
Keyboard
Top:
REAR SPK
Center:
SIDE SPK
Bottom:
CTR BASS
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
USB 2.0
T: USB0
B: USB1
Top:
RJ-45
IDE2
FSB800
DDRII_1 (64/72 bit, 240-pin module)
DDRII_2 (64/72 bit, 240-pin module)
FSB800
DDRII_3 (64/72 bit, 240-pin module)
DDRII_4 (64/72 bit, 240-pin module)
PCIE1
PCI1
PCI2
4Mb
BIOS
LAN
PHY
AUDIO
CODEC
SATA1
SATA2
1
CLRCMOS1
DDRII800
Dual Core CPU
FSB1GHz
Dual Channel
ATA133
SATA
7.1CH HD
RAID
CPU_FAN1
HDLED RESET
PLED PWRBTN
1
PANEL1
CHA_FAN1
SPEAKER1
1
USB6_7
1
USB4_5
1
IR1
FLOPPY1
GAME1
1
HD_AUDIO1
1
RoHS
30.5cm (12.0-in)
20.3cm (8.0-in)
6
7
1
2
4
3
5
8
9
10
11
12
13
14
15
16
17
18
19
2021
22
23
24
25
26
27
28
29
30
31
IDE1
PCIE2
PCIE3
PCI3
1
1
HDMI_SPDIF1
32
JMicron
JMB363
SATAII_1
SATAII_2
Gigabit LAN
SATAII
33
34
1 PS2_USB_PWR1 Jumper 17 Primary Serial ATA Connector (SATA1, Black)
2 ATX 12V Power Connector (ATX12V1) 18 Chassis Speaker Header (SPEAKER 1)
3 CPU Fan Connector (CPU_FAN1) 19 Chassis Fan Connector (CHA_FAN1)
4 CPU Heatsink Retention Module 20 Flash Memory
5 AM2 940-Pin CPU Socket 21 Serial ATAII Connector (SATAII_2, Red)
6 2 x 240-pin DDRII DIMM Slots 22 Floppy Connector (FLOPPY1)
(Dual Channel A: DDRII_1, DDRII_2; Yellow) 23 HDMI_SPDIF Header (HDMI_SPDIF1)
7 2 x 240-pin DDRII DIMM Slots 24 Game Port Header (GAME1)
(Dual Channel B: DDRII_3, DDRII_4; Orange) 25 Front Panel Audio Header (HD_AUDIO1)
8 North Bridge Controller 26 PCI Slots (PCI1- 3)
9 Clear CMOS Jumper (CLRCMOS1) 27 Serial ATAII Connector (SATAII_1, Red)
10 USB 2.0 Header (USB6_7, Blue) 28 PCI Express x1 Slot (PCIE3)
11 USB 2.0 Header (USB4_5, Blue) 29 JMicron JMB363 Chipset (PCIE x1 interface)
12 South Bridge Controller 30 Infrared Module Header (IR1)
13 Primary IDE Connector (IDE1, Blue) 31 PCI Express x1 Slot (PCIE2)
14 Secondary IDE Connector (IDE2, Black) 32 PCI Express x16 Slot (PCIE1)
15 Secondary Serial ATA Connector (SATA2, Black) 33 Internal Audio Connector: CD1 (Black)
16 System Panel Header (PANEL1) 34 ATX Power Connector (ATXPWR1)
