File Name:HBG-240P-SPEC 2016-05-03
※ This series is able to work in either Constant Current mode (a direct drive way) or
Constant Voltage mode (usually through additional DC/DC driver) to drive the LEDs.
DRIVING METHODS OF LED MODULE
Typical output current normalized by rated current (%)
In the constant current region, the highest voltage at the output of the driver
depends on the configuration of the end systems.
Should there be any compatibility issues, please contact MEAN WELL.
100
60
(min.)
Vo(%)
50
100
Io(%)
(B)
Constant
Current area
(C)
Hiccup
Protection
(A)
Constant
V areaoltage
fosc : 100KHz
HBG-240Pseries
240W Constant Voltage + Constant Current LED Driver
BLOCK DIAGRAM
DETECTION
PWM & PFC
CIRCUIT
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.L.P.
PFC
CIRCUIT
PFC
CONTROL
