FM2A55 Pro+
11
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 Chassis Fan Connector (CHA_FAN2)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
5 ATX Power Connector (ATXPWR1)
6 SATA 2 Connector (SATA _2)
7 SATA 2 Connector (SATA _1)
8 Chassis Fan Connector (CHA_FAN1)
9 Chassis Speaker Header (SPEAKER1)
10 System Panel Header (PANEL1)
11 Clear CMOS Jumper (CLRCMOS1)
12 Power LED Header (PLED1)
13 SATA2 Connector (SATA _4)
14 SATA2 Connector (SATA _6)
15 SATA2 Connector (SATA _5)
16 SATA 2 Connector (SATA _3)
17 USB 2.0 Header (USB8_9)
18 USB 2.0 Header (USB6_7)
19 Infrared Module Header (IR1)
20 COM Port Header (COM1)
21
SPDIF Out Connector (HDMI_SPDIF1)
22 Front Panel Audio Header (HD_AUDIO1)
