ASRock A75M-DGS [12/63] Motherboard layout
![ASRock A75M-DGS [12/63] Motherboard layout](/views2/1692424/page12/bgc.png)
12
1.4 Motherboard Layout
1 ATX 12V Power Connector (ATX12V1) 14 Southbridge Controller
2 Power Fan Connector (PWR_FAN1) 15 System Panel Header (PANEL1)
3 CPU Fan Connector (CPU_FAN1) 16 Infrared Module Header (IR1)
4 CPU Socket 17 Print Port Header (LPT1)
5 CPU Heatsink Retention Module 18 USB 2.0 Header (USB6_7)
6 2 x 240-pin DDR3 DIMM Slots 19 Consumer Infrared Module Header (CIR1)
(Dual Channel: DDR3_A1, DDR3_B1) 20 USB 2.0 Header (USB8_9)
7 ATX 12V Power Connector (ATX12V1) 21 COM Port Header (COM1)
8 Chassis Fan Connector (CHA_FAN1) 22 PCI Slot (PCI1)
9 Chassis Speaker Header (SPEAKER1) 23 SPI Flash Memory (32Mb)
10 SATA3 Connector (SATA_4) 24 PCI Express 2.0 x16 Slot (PCIE1)
11 SATA3 Connector (SATA_3) 25 Front Panel Audio Header (HD_AUDIO1)
12 SATA3 Connector (SATA_1) 26 Clear CMOS Jumper (CLRCMOS1)
13 SATA3 Connector (SATA_2)
Super
I/O
CMOS
BATT ER Y
ATXPWR1
AMD
A75 FCH
(Hudson-D3)
Chipset
COM1
PCI1
LAN
AUD IO
COD EC
1
CLRC MOS1
1
CPU _FAN1
HDLED RES ET
PLED PWRBT N
1
PANEL 1
CHA_ FAN1
SPEA KER1
1
HD_A UDIO1
1
32Mb
BIOS
IR1
1
PCIE1
FSB800
DDR3_A1 (64 bit , 240-pin modul e)
DDR3_B1 (64 bit, 240-pin mo dule)
Top:
LIN E IN
Cen ter:
FRO NT
Bot tom:
MIC IN
RJ-45 LAN
1
1
USB 6_7
USB 8_9
A75M-DGS
ErP/EuP Ready
RoHS
DDR3 2400+
USB 2.0
T: USB 0
B: U SB1
CIR1
1
SOCKET FM1
SATA_ 4
SATA_ 3
1
LPT 1
PS2
Mouse
PS2
Keybo ard
VGA1
USB 3.0
T: USB 2
B: U SB 3
Dual Graphics
X
Fast US B
PWR _FAN1
X
Fast LAN
X
Fast RAM
SATA_ 2
SATA_ 1
ATX1 2V1
DX11
1
2 4
3
5
6
7
8
9
10
11
12
13
14
15
16
17
181920
21
22
23
24
25
26
DVI1
USB 3.0
T: USB 4
B: U SB 5
