46
Using SATA3 HDDs without NCQ and Hot Plug functions (IDE mode)
STEP 1: Set up UEFI.
A. Enter UEFI SETUP UTILITY Advanced screen Storage
Con guration.
B. Set the “SATA Mode” option to [IDE].
STEP 2: Install Windows
®
XP / XP 64-bit OS on your system.
2.18 Installing Windows
®
7 / 7 64-bit / Vista
TM
/ Vista
TM
64-bit / XP /
XP 64-bit Without RAID Functions
If you want to install Windows
®
7 / 7 64-bit / Vista
TM
/ Vista
TM
64-bit / XP / XP 64-bit
OS on your SATA3 HDDs without RAID functions, please follow below procedures
according to the OS you install.
2.18.1 Installing Windows
®
XP / XP 64-bit Without RAID Functions
If you want to install Windows
®
XP / XP 64-bit on your SATA3 HDDs without RAID
functions, please follow below steps.
Using SATA3 HDDs with NCQ and Hot Plug functions (AHCI mode)
STEP 1: Set up UEFI.
A. Enter UEFI SETUP UTILITY Advanced screen Storage
Con guration.
B. Set the “SATA Mode” option to [AHCI].
STEP 2: Make a SATA3 Driver Diskette.
Make a SATA3 driver diskette by following section 2.17.1 step 2 on page 44.
STEP 3: Install Windows
®
XP / XP 64-bit OS on your system.
You can start to install Windows
®
XP / XP 64-bit OS on your system. At the begin-
ning of Windows
®
setup, press F6 to install a third-party AHCI driver. When prompt-
ed, insert the SATA3 driver diskette containing the AMD AHCI driver. After reading
the oppy disk, the driver will be presented. Select the driver to install according to
the OS you install.
