1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
SOCKET
7
54
DDR2 (64/72 bit, 184-pin module)
DDR1 (64/72 bit, 184-pin module)
ATXPWR1
IDE1 IDE2
FLOPPY1
CPU_FAN1
PS2_USB_PW1
1
ATX12V1
VIA
VT8237R
Chipset
PCI 1
PCI 2
1.5V_AGP1
FUTURE_CPU_PORT1
VIA
K8M800
Chipset
CMOS
Battery
SATA1 SATA2
CLRCMOS2
1
CHA_FAN1
USB67
1
SPEAKER1
1
IR1
1
HDLED RESET
PLED PWRBTN
1
PANEL 1
GAME1
1
AMR1
4Mb
BIOS
Super
I/O
LAN
PHY
AUDIO
CODEC
AUDIO1
JR1 JL1
1
USB45
CD1
AUX1
1
PARALLEL PORT
VGA1
PS2
Mouse
PS2
Keyboard
USB 2.0
T: USB2
B: USB3
USB 2.0
T: USB0
B: USB1
Top :
RJ-45
Shared
USB 2.0
T: USB4
B: USB5
Top:
Line In
Center:
Line Out
Bottom:
Mic In
DDR400
ATA133
AGP 8X
USB2.0
FSB800
SATA
5.1CH
K8Upgrade-VM800
1
J15
J9
J10
J7
1
J8
1
J5
1
J6
1
J3
1
J4
1
J1
1
J2
1
1
1
COM1
1
24.4cm (9.6-in)
22.9cm (9.0-in)
1
2
4
3
16
19
17
18
57
8
9
11
13
14
15
12
10
6
202122232425
26
32
33
30
27
29
28
31
34
8
1 PS2_USB_PWR1 Jumper 18 System Panel Header (PANEL1)
2 ATX 12V Power Connector (ATX12V1) 19 Game Port Header (GAME1)
3 CPU Fan Connector (CPU_FAN1) 20 Chassis Speaker Header (SPEAKER 1)
4 754-Pin CPU Socket 21 USB 2.0 Header (USB67, Blue)
5 CPU Heatsink Retention Module 22 Chassis Fan Connector (CHA_FAN1)
6 North Bridge Controller 23 Clear CMOS Jumper (CLRCMOS2)
7 184-pin DDR DIMM Slots (DDR1- 2) 24 AGP Slot (1.5V_AGP1)
8 J9 / J10 / J15 Jumpers 25 COM Port Header (COM1)
9 Infrared Module Header (IR1) 26 AMR Slot (AMR1)
10 Flash Memory 27 PCI Slots (PCI1- 2)
11 ATX Power Connector (ATXPWR1) 28 JR1 / JL1 Jumpers
12 Floppy Connector (FLOPPY1) 29 Front Panel Audio Header (AUDIO1)
13 Primary IDE Connector (IDE1, Blue) 30 Future CPU Port (FUTURE_CPU_PORT1)
14 Secondary IDE Connector (IDE2, Black) 31 Internal Audio Connector: AUX1 (White)
15 South Bridge Controller 32 Internal Audio Connector: CD1 (Black)
16 Primary Serial ATA Connector (SATA1) 33 Shared USB 2.0 Header (USB45, Blue)
17 Secondary Serial ATA Connector (SATA2) 34 J1 - J8 Jumpers
