1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
Super
I/O
CMOS
BATTERY
ATXPWR1
SOCKET 939
CD1
AMD
785G
Chipset
ATX 12 V1
PS2_USB_PW1
1
COM1
IDE1
PCIE1
PCI1
PCI2
LAN
AUDIO
CODEC
1
CLRCMOS1
1
CPU_FAN1
HDLED RESET
PLED PWRBTN
1
PANEL1
CHA_FAN1
SPEAKER1
1
FLOPPY1
HD_AUDIO1
1
RoHS
24.4cm (9.6-in)
21.8cm (8.6-in)
6
7
1
2
4
3
5
8
9
12
13
14
15
16
17
18
19
20
21
22
23
24
2526
27
28
29
30
31
32
8Mb
BIOS
IR1
1
Gigabit LAN
AMD
SB710
Chipset
USB8_9
1
PCIE2
939A785GMH
DDR400
33
Top:
SIDE SPK
Center:
REAR SPK
Bottom:
SPDIF_01
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
PS2
Keyboard
USB 2.0
T: USB 0
B: USB1
Top:
RJ-45
VGA1
DVI_CON1
HDMI1
FSB800
DDR1 (64 bit, 184-pin module)
DDR2 (64 bit, 184-pin module)
FSB800
DDR3 (64 bit, 184-pin module)
DDR4 (64 bit, 184-pin module)
SATAII_1
(
SATAII_2
PORT 0) (PORT 1)
SATAII_3
(
SATAII_4 SATAII_5
PORT 2) (PORT 3) (PORT4)
Dual Channel
PCI Express 2.0
EuP Ready
Hybrid CrossFire
PWR_FAN1
34
USB 2.0
T:USB2
B: USB3
eSATAII_1
USB6_7
1
USB4_5
1
1
LPT1
10
11
1 PS2_USB_PW1 Jumper 19 Third SATAII Connector (SATAII_3 (PORT 2))
2 ATX 12V Power Connector (ATX12V1) 20 Secondary SATAII Connector
3 CPU Heatsink Retention Module (SATAII_2 (PORT 1))
4 939-Pin CPU Socket 21 Primary SATAII Connector
5 CPU Fan Connector (CPU_FAN1) (SATAII_1 (PORT 0))
6 2 x 184-pin DDR DIMM Slots 22 Chassis Speaker Header
(Dual Channel A: DDR1, DDR2; Blue) (SPEAKER 1, White)
7 2 x 184-pin DDR DIMM Slots 23 System Panel Header (PANEL1, White)
(Dual Channel B: DDR3, DDR4; Black) 24 SPI Flash Memory (8Mb)
8 ATX Power Connector (ATXPWR1) 25 Print Port Header (LPT1, White)
9 Primary IDE Connector (IDE1, Blue) 26 Floppy Connector (FLOPPY1)
10 USB 2.0 Header (USB8_9, Blue) 27 Serial Port Connector (COM1)
11 USB 2.0 Header (USB6_7, Blue) 28 Internal Audio Connector: CD1 (Black)
12 USB 2.0 Header (USB4_5, Blue) 29 Front Panel Audio Header
13 Power Fan Connector (PWR_FAN1) (HD_AUDIO1, White)
14 Clear CMOS Jumper (CLRCMOS1) 30 Infrared Module Header (IR1)
15 Southbridge Controller 31 Northbridge Controller
16 Chassis Fan Connector (CHA_FAN1) 32 PCI Express 2.0 x16 Slot (PCIE2; Blue)
17 Fifth SATAII Connector (SATAII_5 (PORT 4)) 33 PCI Express 2.0 x1 Slot (PCIE1; White)
18 Fourth SATAII Connector (SATAII_4 (PORT 3)) 34 Northbridge Controller
