25
Chipset Configuration:
OnBoard VGA Share Memory: This allows you to select the size of share
memory for onboard VGA. Onboard VGA will get better resolution if larger
size of share memory is selected.
AGP Aperture Size: It refers to a section of the PCI memory address range
used for graphics memory. It is recommended to leave this field at the
default value unless the installed AGP card’s specifications requires other
sizes.
USB Controller: Use this to enable or disable the use of USB controller.
USB 2.0 Controller: Use this to enable or disable USB 2.0 controller. If this is
set to [Disabled], USB Controller will run at USB 1.1.
USB Device Legacy Support: Use this to enable or disable the support to
emulate legacy I/O devices such as mouse, keyboard,... etc.
DRAM CAS Latency: This is used to adjust the means of memory accessing.
Configuration options: [Auto], [2T], [2.5T], [3T].
Please note that not all the DDR DIMMs can support CAS latency=3T.
Over Vcore Voltage: This feature allows you to increase the CPU Vcore
voltage by 3% or 6%. The default value is [Disabled].
It is not recommended to enable “Over Vcore Voltage” feature.
Doing so may cause CPU damage.
AMIBIOS SETUP UTILITY - VERSION 3.31a
Advanced
Onboard VGA Share Memory
AGP Aperture Size
USB Controller
USB 2.0
USB Device Legacy Support
Over Vcore Voltage
Controller
DRAM CAS Latency
[ Setup Help ]
F1:Help
Esc:Previous Menu
F9:Setup Defaults
F10:Save & Exit
+/-:Change Values
Enter:Select
Sub-Menu
:Select Item
Chipset Configuration
64M
Enabled
Enabled
Disabled
Auto
Disabled
<Enter> to set the
share memory size of
the onboard VGA..
Auto
