3. Power Setup Menu
Suspend to RAM (S3): This field allows you to select whether to auto-detect or
disable “ACPI S3” feature. Select [Auto] will enable this feature if the system
supports it.
Repost Video on S3 Resume: This feature allows you to repost video on S3
resume. It is recommended to enable this feature under Microsoft
®
Windows
®
98 / ME.
Restore on AC/Power Loss: This allows you to set the power state after an
unexpected AC/power loss. If [Power Off] is selected, the AC/power remains
off when the power recovers. If [Power On] is selected, the AC/power
resumes and the system starts to boot up when the power recovers.
Ring-In Power On: Use this to enable or disable Ring-in signals to turn on the
system from the power-soft-off mode.
PCI Devices Power On: Use this to enable or disable PCI devices to turn on the
system from the power-soft-off mode.
PS/2 Keyboard Power On: Use this to enable or disable PS/2 keyboard to turn on
the system from the power-soft-off mode.
RTC Alarm Power On: Use this to enable or disable RTC (Real Time Clock) to
power on the system. If [Enable] is selected, you must fill the RTC Alarm Date /
Hour / Minute / Second sub-fields with the actual wake up time you desire.
AMIBIOS SETUP UTILITY - VERSION 3.31a
Main
Advanced
Security
Power
Boot
Exit
Suspend To RAM (S3)
Repost Video on S3 Resume
Restore on AC / Power Loss
Ring-In Power On
PCI Devices Power On
PS / 2 Keyboard Power On
RTC Alarm Power On
RTC Alarm Date
RTC Alarm Hour
RTC Alarm Minute
RTC Alarm Second
[ Setup Help ]
<Enter> to select
auto-detect or disable
the ACPI S3 feature.
F1:Help
Esc:Exit
F9:Setup Defaults
F10:Save & Exit
+/-:Change Values
Enter:Select
Sub-Menu
:Select Item
:Select Menu
Disabled
Disabled
Power Off
Disabled
Disabled
Disabled
Disabled
Everyday
12
30
