ASRock DeskMini A300 Series [7/56] Platform
![ASRock DeskMini A300 Series [7/56] Platform](/views2/1692745/page7/bg7.png)
English
2
1.2 Specications
Platform
•
Mini-STX Form Factor
•
Solid Capacitor design
CPU
•
Supports AMD AM4 Socket CPUs (Picasso, Raven Ridge,
Bristol Ridge, up to 65W)
* Please refer to the "CPU Support List" on ASRock's website for
more information.
•
Supports CPU up to 65W
•
5 Power Phase design
Chipset
•
AMD A300
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 SO-DIMM Slots
•
AMD Ryzen series CPUs (Raven Ridge) support DDR4
2933/2667/2400/2133 non-ECC, un-buered memory*
•
AMD 7
th
Gen A-Series APUs support DDR4 2400/2133 non-
ECC, un-buered memory*
* Please refer to page 19 for DDR4 SO-DIMM maximum
frequency support.
•
Max. capacity of system memory: 64GB
•
15μ Gold Contact in SO-DIMM Slots
Expansion
Slot
•
1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
•
Integrated AMD Radeon
TM
R-Series Graphics in A-series
APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* e Max shared memory 16GB requires 32GB system memory
installed.
