1.5 System Chassis1.5 System Chassis

1.5 System Chassis

Opening the system chassis

1. Remove the screws on the backside.

2. Slide the top panel backwards.

25. Optical Disc Drive

26. Power ON/OFF button with status indicator

27. Drive activity indicator

28. Headphone

29. Microphone

30. USB3.0 ports: USB devices
