16
ATX/AT Mode Jumper Open : ATX Mode
(2-pin SIO_AT1)
Close : AT Mode
(see p.8, No. 19)
1
LVDS Switch Open : LVDS
(2-pin LVDS_SWITCH1)
Close : eDP
(see p.8, No. 17)
1
