Chapter 1: Introduction
Thank you for purchasing ASRock
IMB-1211-D / IMB-1211-L / IMB-1210-D / IMB-
1210-L
motherboard, a reliable motherboard produced under ASRock’s consistently
stringent quality control. It delivers excellent performance with robust design con-
forming to ASRock’s commitment to quality and endurance.
In this manual, chapter 1 and 2 contain introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration
guide to BIOS setup and information of the Support CD.
Because the motherboard specications and the BIOS software might be
updated, the content of this manual will be subject to change without no-
tice. In case any modications of this manual occur, the updated version
will be available on ASRock website without further notice. You may nd
the latest VGA cards and CPU support lists on ASRock website as well.
ASRock website http://www.asrock.com
If you require technical support related to this motherboard, please visit
our website for specic information about the model you are using.
www.asrock.com/support/index.asp
1.1 Package Contents
ASRock
IMB-1211-D / IMB-1211-L / IMB-1210-D / IMB-1210-L
Motherboard
(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)
ASRock
IMB-1211-D / IMB-1211-L / IMB-1210-D / IMB-1210-L
Driver CD
ASRock
IMB-1211-D / IMB-1211-L / IMB-1210-D / IMB-1210-L
Jumper setting in-
struction
1 x I/O Panel Shield
