9
Rear I/O
VGA 1
HDMI N/A
DisplayPort 2
Ethernet 2
USB 4 x USB support USB3.1
Audio 2 (Mic-in, Line-out)
Serial 2 x COM(RS-232/422/485)
PS2 N/A
Internal
Connector
USB 4 x USB 2.0
LVDS/
inverter
1
eDP N/A
VGA N/A
Serial 3 x COM(RS-232)
SATA 4 x SATA3 (6.0Gb/s)
GPIO 4 x GPI, 4 x GPO
SATA PWR
Output
N/A
Speaker
Header
1
TPM 1 x Onboard TPM 2.0 IC
Watchdog
Timer
Output From super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec
Power
Requirements
Input PWR ATX PWR 24+4-pin
Power On
AT/ATX Supported
AT: Directly PWR on as Power input ready
ATX: Press Button to PWR on after Power
input ready
Environment
Operating
Temp
0ºC – 60ºC
Storage
Temp
-40ºC – 85ºC
