DisplayPort 2
Ethernet 2
USB 4 x USB 3.0 compliant
Audio 2 (Mic-In, Line-Out)
Serial 2 (RS-232/422/485)
PS/2 0
Internal
Connector
USB
- 8 (4 x USB Header 2.54mm pitch)
- 1 Vertical Type A USB Connector
LVDS/
Inverter
24 bit dual channel LVDS
VGA 0
Serial 4 (RS-232)
SATA
4 x SATA3 (6.0Gb/s), Support RAID
0/1/5/10
mPCIe 1
Parallel 1
mSATA 1
IrDA 0
GPIO 8-bit 4 x GPI + 4 x GPO
SATA PWR
Output Con
1
Speaker
Header
0
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR DC-in 12V~19V
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
