10
1 Backlight & Amp Volume Control Header (BLT_VOL1)
2 LVDS Panel Connector (LVDS1)
3
Panel Power Jumper (PNL_PWR1)
4
Inverter Power Control Header (BLT_PWR3)
5
CPU FAN Connector (CPU_FAN1)
6
Chassis FAN Connector (CHA_FAN1)
7 ATX 12V Power Connector (DC12V1)
8
SATA Power Connector (SATA_PWR1)
9
Half-size mini PCIE Connector (PCIE1)
10
SATA2 Connector (SATA2_1)
11
SATA2 Connector (SATA2_2)
12 System Panel Header (PANEL1)
13 ATX/AT Mode Jumper (PWR_JP1)
14 Printer Port Header (LPT1)
15 COM Port Power Setting Jumper (COM_PWR4)
16 COM Port Power Setting Jumper (COM_PWR5)
17 COM Port Power Setting Jumper (COM_PWR6)
18 Clear CMOS Header (CLRCMOS1)
19 COM Port Header (COM4)
20 COM Port Header (COM5)
21 COM Port Header (COM6)
22 GPIO& Header (DGIO_AMP1)
23
USB2.0 Connector (USB_4_5)
24
USB2.0 Connector (USB_6_7)
25
PCI Slot (PCI1)
26
Buzzer (BUZZ1)
27 Internal Speaker Header (SPEAKER1)
28
VGA Header (VGA_H1)
