11 : BL1
12 : LVDS Panel Connector
13 : BL2
14 : SATA2 Connectors
(SATAII_1, SATAII_2)
1
5 : SATA Power Output Connector
16 :
System Panel Header
6 : Clear CMOS Headers
CLRMOS1:
1-2 : Normal
2-3 : Clear CMOS
CLRMOS2:
Open : Normal
Short : Auto Clear CMOS When AC
Power On
7 : Backlight & Amp Volume Control
(BLT_VOL1)
8 : Inverter Power Control Wafer
(BLT_PWR1)
9 :
mSATA Select (MSATA_SEL1)
1-2 : SATAII_2 + mini-PCIe
2-3 : mSATA, SATAII_2 no function
10 : Backlight Control Level
(BLT_PWM1)
1-2 : +3V
2-3 : +5V
1 : LPC Header
2 :
3-Pin Chassis FAN Connector (+12V)
3 :
USB2.0 Headers
(USB2H_2_3, USB2H_4_5)
(USB2_0_1)
4
: Backlight Power Selection
(LCD_BLT_VCC)
(BKT_PWR1)
1-2 : +5V
2-3 : +12V
3-4 : +12V
4-5 : DC_IN Power
5 : Panel Power Selection (LCD_VCC)
(PNL_PWR1)
1-2 : +3V
2-3 : +5V
3-4 : +5V
4-5 : +12V
Jumpers and Headers Setting Guide
SBC-212-WT
The terms HDMI™ and HDMI High-Denition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
BIOS
Chip
18
21
23
26
32
27
29
19
20
2224
25
28
35
31
30
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
CPU_FAN1
PWR _JP1
1
1
JGPIO1
mini-PCIe
1
LPC1
CHA_FA N1
SPEAK ER1
1
LAN1
VGA1
Line Out
HDMI1
1
BLT_ VOL1
HDLED R ESET
PLED PWRBT N
PANEL1
1
mini-PCIe / mini-SATA
CI1
1
SATA_ PW R 1
LVDS1
1
1
BLT_ PW R1
SE T _C M1
LAN2
T: USB 2.0
B: USB 3.0
COM4
COM3 COM2 COM1
CI2
1
BUZZ 1
1
DDR3 (Support DDR3L Only)
ATX12V1
1
BKT _PW R1
1
PNL _PW R1
1
SATAI I_ 1
SATAI I_ 2
BLT_P WM1
MSATA_ SEL1
34
1
HD_AUDIO1
1
33
1
JGP IO_S ET1
1
JGP IO_P WR1
1
EDP _LVDS _J2
1
1
USB2H _2_3
1
USB2H _4_5
1
USB2_ 0_1
1
1
1
1
1
1
BL2
BL1
CLR MOS1
CLR MOS2
DUMMY
GND GND
+B
-B
+A
-A
USB_PWR
USB_PWR
1
1
1
SATAII_2
SATAII_1
1
GND
GND
S_PWRDWN#
LAD2
SMB_CLK_MAIN
PCICLK
PCIRST #
LAD3
+3V
LAD0
GND
FRAME
SMB_DATA_MAIN
LAD1
SERIRQ#
GND
+3VSB
48MHz
+5V
GND
+ 12V
CHA_ FAN_SPEED
NC
PIN Signal Name
7 GND
6 GND
5 GPIO_BLT_DW
4 GPIO_BLT_UP
3 PWRDN
2 GPIO_VOL_DW
1 GPIO_VOL_UP
PIN Signal Name
6 LCD_BLT_VCC
5 LCD_BLT_VCC
4 CON_LBKLT_EN
3 CON_LBKLT_CTL
2 GND
1 GND
1
1
39
40
2
PIN Signal Name PIN Signal Name
39 LCD_BLT_VCC 40 LCD_BLT_VCC
37
CON_LBKLT_CTR
38 LCD_BLT_VCC
35 GND9 36
CON_LBKLT_EN
33 LVDS_B_CLK# 34 LVDS_B_CLK
31 LVDS_B_DATA3 32 GND5
29 DPLVDD_EN 30 LVDS_B_DATA3#
27 LVDS_B_DATA2# 28 LVDS_B_DATA2
25 LVDS_B_DATA1 26 GND4
23 GND8 24 LVDS_B_DATA1#
21 LVDS_B_DATA0# 22 LVDS_B_DATA0
19 LVDS_A_CLK 20 GND3
17 GND7 18 LVDS_A_CLK#
15 LVDS_A_DATA3# 16 LVDS_A_DATA3
13 LVDS_A_DATA2 14 GND2
11 GND6 12 LVDS_A_DATA2#
9 LVDS_A_DATA1# 10 LVDS_A_DATA1
7 LVDS_A_DATA0 8 GND1
5 N/A 6 LVDS_A_DATA0#
3 +3V 4 N/A
1 LCD_VCC 2 LCD_VCC
1
GND
RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
GND
GND
+5V
+12V
GND
1
1
