13 : SATA3 Connector (SATA3_1)
14 : Panel Power Selection (LCD_VCC)
(PNL_PWR1)
1-2 : +3V
2-3 : +5V
3-4 : +5V
4-5 : +12V
15 : ATX/AT Mode Select
1-2 : AT Mode
2-3 : ATX Mode
16
: SATA Power Output Connector
17 :
System Panel Header
18 : 4-pin DC-in PWR Connector
(Input +12V ~ +24V)
1-4 : GND
2-3 : DC Input
19 : LPC Header
8 : USB3 Power Setting Jumper
(for USB3_2_3)
1-2: +5V
2-3: +5VSB
9 : Backlight Control Level
(BLT_PWM1)
1-2 : +3V
2-3 : +5V
10 : Inverter Power Control Wafer
(BLT_PWR1)
11 : Backlight & Amp Volume Control
(BLT_VOL1)
12
: Backlight Power Select
(LCD_BLT_VCC)
(BKT_PWR1)
1-2 : +5V
2-3 : +12V
3-4 : +12V
4-5 : DC_IN Power
1 : USB3 Power Setting Jumper
(for USB3_0_1)
1-2: +5V
2-3: +5VSB
2 : Clear CMOS Header
1-2 : Normal
2-3 : Clear CMOS
3 :
4-Pin FAN Connector (+12V)
4 : 2-Pin Buzzer Header
5 :
USB2.0 Header
(USB2H_1_2)
6 : USB2 Power Setting Jumper
(for USB2H_1_2)
1-2: +5V
2-3: +5VSB
7 :
USB3.0 Header
(USB3_2_3)
Jumpers and Headers Setting Guide
SBC-220
PIN Signal Name
1 GPIO_VOL_UP
2 GPIO_VOL_DW
3 PWRDN
4 GPIO_BLT_UP
5 GPIO_BLT_DW
6 GND
7 GND
1
DUMMY
GND GND
+B
-B
+A
-A
USB_PWR
USB_PWR
1
PIN Signal Name
1 GND
2 GND
3 CON_LBKLT_CTL
4 CON_LBKLT_EN
5 LCD_BLT_VCC
6 LCD_BLT_VCC
1
GND RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
GND
+5V
+12V
1
GND
GND
FAN_SPEED
FAN_SPEED_CONT ROL
+12V
GND
1
2
3
4
1
+5V
SPKR
1
GND
GND
S_PWRDWN#
LAD2
SMB_CLK_MAIN
PCICLK
PCIRST#
LAD3
+3V
LAD0
GND
FRAME
SMB_DATA_MAIN
LAD1
SERIRQ#
GND
+3VSB
48MHz
+5V
BIOS
Chip
FAN1
1
JGPIO1
mini-PCIe
1
LPC1
SPEAKER1
1
LAN1
HDMI1
PWR_JP1
HDLED RESET
PLED PWRBT N
PANEL1
1
CI1
1
SATA_ PW R 1
LVDS1
1
1
BLT_ VOL1
1
BLT_PW R1
USB 3.0
T: USB1
B: USB0
COM1
COM2 COM3 COM4
JGP IO_P WR1
1
CLR MOS1
1
BUZ Z1
1
DDR3 (Support DDR3L Only)
1
PNL _PW R 1
1
SATA3 _1
LAN2
CI2
1
ATX1 2V1
1
PWR _COM 1
1
PWR _COM 2
1
PWR _COM 3
1
PWR _COM 4
1
JGP IO_S ET1
1
VGA1
Mic In
Line Out
mini-SATA
PWR U3_0 1
1
1
USB 2H_1 _2
USB3_2_3
PWR U2H
1
BKT _PW R1
1
BLT_ PWM1
1
PWR U3_2 3
1
13
12
11
1
9
3
2
4
5
6
7
8
10
16
17
14
15
18
21
22
19
2023
24
27
28
25
26
31
32
29
30
33
39
40
38
37
36
35
34
1
IntA_P1_D+
ID
IntA_P1_D-
GND
IntA_P1_SSTX+
GND
IntA_P1_SSTX-
IntA_P1_SSRX+
IntA_P1_SSRX-
VbusVbus
Vbus
IntA_P0_SSRX-
IntA_P0_SSRX+
GND
IntA_P0_SSTX-
IntA_P0_SSTX+
GND
IntA_P0_D-
IntA_P0_D+
*15G06M030001AK*
P/ N: 15G06M030001AK V1.1
