ASRock SBC-210N Руководство по настройке перемычек онлайн

ASRock SBC-210N Руководство по настройке перемычек онлайн
14 : Clear CMOS Header
1-2 : Normal
2-3 : Clear CMOS
15 : Digital Input / Output Pin Header
16 : Digital Input / Output Power select
1-2 : +12V
2-3 : +5V
COM1, 2, 3, 4 Headers
17 : COM4
19 : COM3
21 : COM2
23 : COM1
7 : SATA2 Connectors
(SATAII_1, SATAII_2)
8 : Backlight & Amp Volume Control
(BLT_VOL1)
9 : Backlight Control Level
(BLT_PWM1)
1-2 : +3V
2-3 : +5V
10 :
3-Pin Chassis FAN Connector (+12V)
11 :
System Panel Header
1
2 : SATA Power Output Connector
1
3 : GPIO Default Setting
1-2 : Pull-High
2-3 : Pull-Low
1 : Panel Power Selection (LCD_VCC)
(PNL_PWR1)
1-2 : +3V
2-3 : +5V
3-4 : +5V
4-5 : +12V
2 : ATX Power Connector
(Input 9V-36V)
1-4 : GND
2-3 : DC Input
3
: Backlight Power Selection
(LCD_BLT_VCC)
(BKT_PWR1)
1-2 : +5V
2-3 : +12V
3-4 : +12V
4-5 : DC_IN Power
4 :
USB2.0 Headers
(USB0_1, USB2_3,
USB4_5)
5 :
mSATA Selection
1-2 : SATAII_2 + mini-PCIe
2-3 : mSATA, SATAII_2 no function
6 : Inverter Power Control Wafer
(BLT_PWR1)
Jumpers and Headers Setting Guide
SBC-210
PIN Signal Name PIN Signal Name
1 SIO_GP24 2 SIO_GP20
3 SIO_GP25 4 SIO_GP21
5 SIO_GP26 6 SIO_GP22
7 SIO_GP27 8 SIO_GP23
9 JGPIO_PWR 10 GND
1
2
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
PIN
Signal
Name
10 DUMMY 8 CCTS# 6 DDSR# 4 DDTR# 2 RRXD
9
DUMMY
7
RRTS#
5
GND
3
TTXD
1
DDCD#
PIN RS232 RS422 RS485
1 DCD TX- RTX-
2 RXD RX+ N/A
3 TXD TX+ RTX+
4 DTR RX- N/A
5 GND GND GND
6 DSR N/A N/A
7 RTS N/A N/A
8 CTS N/A N/A
9 NA/+5V/+12V N/A N/A
* This motherboard supports RS232/422/485 on COM1 port. Please refer to below
table for the pin denition. In addition, COM1 port (RS232/422/485) can be adjusted
in BIOS setup utility > Advanced Screen > Super IO Conguration. You may refer to
page 29 of our user manual for details.
COM1 Port Pin Denition
DUMMY
GND GND
+B
-B
+A
-A
USB_PWR
USB_PWR
1
PIN Signal Name
1 GND
2 GND
3 CON_LBKLT_CTL
4 CON_LBKLT_EN
5 LCD_BLT_VCC
6 LCD_BLT_VCC
1
1
1
1
GND
RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
GND
PIN Signal Name
1 GPIO_VOL_UP
2 GPIO_VOL_DW
3 PWRDN
4 GPIO_BLT_UP
5 GPIO_BLT_DW
6 GND
7 GND
1
+5V
+1 2 V
1
GND
GND
SATAII_2
SATAII_1
The terms HDMI
®
and HDMI High-Denition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
