7
Rear I/O
VGA 1 x D-Sub
DVI 0
HDMI 1
DisplayPort 0
Ethernet 1
USB 4 (USB 2.0 compliant)
Audio 2 (Mic-in, Line-out)
Serial 1 (RS-232/422/485) + 1 (RS232)
PS/2 2 (1 x keyboard and 1 x mouse)
Internal
Connector
USB 3 (USB 2.0 compliant)
LVDS/
Inverter
1/1
VGA 0
Serial 3 (RS-232)
SATA 2 x SATA2 (3.0Gb/s)
mPCIe 1
Parallel 1
mSATA 0
IrDA 0
GPIO 8-bit 4 x GPI + 4 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR 12V DC-In (4-pin ATX PWR Con)
Power On
AT/ATX Supported
-AT : Directly PWR on as power input ready
-ATX : Press button to PWR on after power
input ready
Environment Temperature 0ºC – 60ºC
