7
SATA
Max Data
Transfer
Rate
SATA3 (6.0Gb/s)
Rear I/O
VGA 0
HDMI 2
DVI-I/D 0
DisplayPort 0
Ethernet 2
USB 4 x USB 3.0
Audio 0
Serial 0
e-SATA 0
PS/2 0
Internal
Connector
USB 4 (2 x USB Header 2.54mm pitch)
LVDS/
Inverter
24 bit dual channel LVDS co-lay with eDP
VGA 0
Serial 4 (2 RS-232/422/485, 2 RS-232)
SATA 2 x SATA3 (6.0Gb/s)
m-SATA 1 (shared)
Mini-PCIe 1
Parallel 0
IrDA 0
GPIO 4 x GPI + 4 x GPO
SATA PWR
Output Con
1
Speaker
Header
1
Watchdog
Timer
Output Output from super I/O to drag RESETCON#
Interval 256 Segments, 0,1,2…255 Sec/Min
Power
Requirements
Input PWR DC 9-36 input
Power On
AT/ATX Supported
AT: Directly PWR on as power input ready
ATX: Press button to PWR on after power
input ready
Environment
Temperature 0ºC – 60ºC
