8. 4-Pin PCIe Power Connector (PWR_PCIE1)
9. PCIe x4 Pin A1*
10. PCIe x4 Pin A32*
* PCIe x4 Pin Denition
Specications
Function
•
PCIE x4 to 4 x 2.5G PoE LAN Card
Form Factor
•
PCIe x4 Add on Card
Controller / Major IC
•
ASM2812
Input I/F
•
PCIe 2.0 x 4
•
Power Con 4 PIN +12V
Output I/F
•
up to 4 x 2.5G RJ45 Ports
TDP
•
60W
Dimensions (W x L x H/mm)
•
176 x 111 x 15.1
Operating Temperature
•
0°C ~ 70°C
Storage Temperature
•
-40° C ~ 85° C
+5V
GND
+12V
PIN Signal Signal PIN
B1 +12V PRSNT1# A1
B2 +12V +12V A2
B3
+12V +12V
A3
B4
GND GND
A4
B5
SMCLK TCK
A5
B6 SMDAT TDI A6
B7 GND TDO A7
B8 +3.3V TMS A8
B9 TRST# +3.3V A9
B10
+3.3V aux +3.3V
A10
B11
WAKE# PERST#
A11
B12
CLKREQ# GND
A12
B13
GND REFCLK+
A13
B14
HSOp (0) REFCLK-
A14
B15
HSOp (0) GND
A15
B16
GND HSIp (0)
A16
B17 PRSNT2# HSIp (0) A17
B18
GND GND
A18
B19 HSOp (1) Reserved A19
B20 HSOp (1) GND A20
B21 GND HSIp (1) A21
B22 GND HSIp (1) A22
B23 HSOp (2) GND A23
B24 HSOp (2) GND A24
B25 GND HSIp (2) A25
B26 GND HSIp (2) A26
B27 HSOp (3) GND A27
B28
HSOp (3) GND
A28
B29
GND HSIp (3)
A29
B30 Reserved HSIp (3) A30
B31
PRSNT2# GND
A31
B32
GND Reserved
A32
