The Digital Controller ESIE10-01

2–18 Part 2 – Functional Description

The following set points exist individually for each circuit:

Slide Load Delay Maximum 150 seconds 60 to 300 seconds

Slide Unload Delay Minimum 10 seconds 5 to 20 seconds

Slide Unload Delay Maximum 50 seconds 30 to 75 seconds

Liquid Injection Activation 85°C 75 to 90°C

Liquid Line Solenoid Valves No No, Yes

Alarm Limits SI

Low Evap Pressure-Unload 190 KPA See auto adjusted settings

Low Evap Pressure-Hold 200 KPA See auto adjusted settings

Oil Press Delay 30 sec 10-180 sec

Oil Press Differential 250 KPA 0 to 415 KPA

Low Oil Level Delay 120 sec 10 to 180 sec

High Discharge Temperat. 110°C 65 to 110°C

High Lift Pressure Delay 5 sec 0 to 30 sec

Low Pressure Ratio Delay 90 sec 30-300 sec

Start Time Limit 60 sec 20 to 180 sec

Evaporator Water Freeze 2.2°C See auto adjusted settings

Evaporator Flow Proof 15 sec 5 to 15 sec

Recirculate Timeout 3 min 1 to 10 min

Low Ambient Lockout Enable Disable Disable, Enable

Low Ambient Lockout 12°C See auto adjusted settings

Description Default Range

Circuit mode Enable Disable, enable, test

Compressor Size To be Veri-

fied

Capacity Control Auto Auto, Manual

Manual Capacity See note 1

below table

0 to 100%

Clear Cycle Timers No No, yes

EXV control Auto Auto, manual

EXV position See note 2

below table

0 to 100%

Oil Sump Check Enable Enable, Disable

Service Pumpdown No No, Yes

Evap pressure offset 0 KPA -100 to 100 KPA
