Introduction EDBE81-327
6 Photocatalytic Air Purifiers
䇭
䇭䇭
䇭Childproof function
Even if a curious child
handles the controller,
the childproof ensures
continued operation at
the chosen settings.
Childproof display
Remote controller
holder
Have you ever
wondered where the
remote controller has
gone? In the new
design, look for it in
the storage space at
the top of the unit.
䇭
䇭䇭
䇭Easy to carry
With one hand free
it's easy to open
doors and carry the
unit from one room to
another.
A Variety of Convenient Functions
A Variety of Convenient FunctionsA Variety of Convenient Functions
A Variety of Convenient Functions
