C3758D4I-4L / C3558D4I-4L
Quick Installation Guide
www.asrockrack.com
C3758D4I-4L C3558D4I-4L
Activity / Link LED Speed LED
Status Description Status Description
O No Link O No Link
Blinking Yellow Data Activity O 10M bps connection
On Link Yellow 100M bps connection
Green 1G bps connection
6 LAN Port LED Indications5 Install the Power Cables
LAN Port
System Panel
Auxiliary Panel
8
7
1
Before installing an expansion card, please make sure that the power supply is switched o or the power
cord is unplugged. Please read the documentation of the expansion card and make necessary hardware
settings for the card before you start the installation.
2
Remove the system unit cover (if your motherboard is already installed in a chassis).
Remove the bracket facing the slot that you intend to use. Keep the screws for later use.
Align the card connector with the slot and press rmly until the card is completely seated on the slot.
Fasten the card to the chassis with screws.
Replace the system cover.
4
5
6
3V
3V
GND
GND
5V
5V
GND
PWROK_PS
5VSB
12V
12V
3V
121
13
24
3V
-12V
GND
PSON#
GND
GND
GND
5V
5V
5V
GND
N/A
GND
RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
GND
Headers
3
9
Install the Memory
Install the PCIE Card
1
2
3
Unlock a DIMM slot by pressing
the module clips outward.
Insert the memory module.
Lock the clips.
IMPI LAN Port
*Images shown are for illustrative purposes only and may dier depending on model.
4
8
1
5
12V
GND
ACT/LINK LED
SPEED LED
LAN Port
Speed LED Activity / Link LED
Status Description Status Description
O 10Mbps connection or
no link
O No Link
Yellow 100Mbps connection Blinking Green Data Activity
Green 1Gbps connection On Link
ACT/LINK LED
SPEED LED
LAN Port
GND
BMC_SMBCLK1
BMC_Alert1_N
CASEO PEN#
1
SMB_SMBDATA1
+3VSB
LAN1_LINK
LED_PWR
LAN2_LINK
LED_PWR
+5VSB
GND
GND
LOCATORLED+
LOCATORLED-
LOCATORBTN#
System_Fault_LED_N
System_Fault_LED_P
A
B
CD
E
PCIE7 (PCIE 3.0 x8 slot) is used for PCI Express max x8 lane width cards.
Slot Generation Mechanical Electrical Source
PCIE 7 3.0 x8 x8 / x4 CPU
Dual Channel Memory Conguration
Priority
DDR4_A1
(Blue)
DDR4_A21
(White)
DDR4_B1
(Blue)
DDR4_B2
(White)
1 Populated Populated
2 Populated Populated Populated Populated
