C3758D4U-2TP / C3558D4U-2OP
24 25
English
Serial ATA3 Connectors
(SATA_1)
(SATA_1)
(SATA_2)
(SATA_3)
(M0_SATA0)
(M0_SATA1)
(M1_SATA0)
(M1_SATA1)
M0_S AT A1
M0_S AT A0
M1_S AT A1
M1_S AT A0
SA TA_0
SA TA_1
SA TA_2
SA TA_3
ese seven Serial ATA3
(SATA3) connectors support
SATA data cables for internal
storage devices. e current
SATA3 interface allows up to
6.0 Gb/s data transfer rate.
Auxiliary Panel Header
(18-pin AU X_ PANEL1)
GND
BMC_SMBCLK1
BMC_Alert1_N
CASEOPEN#
1
SMB_SMBDATA1
+3VSB
LAN1_LINK
LED_PWR
LAN2_LINK
LED_PWR
+5VSB
GND
GND
LOCATORLED+
LOCATORLED-
LOCATORBTN#
System_Fault_LED_N
System_Fault_LED_P
A
B
CD
E
is header supports multiple
functions on the front panel,
including front panel SMB,
internet status indicator.
A. Front panel SMBus connecting pin (6-1 pin FPSMB)
is header allows you to connect SMBus (System Management Bus) equipment. It can
be used for communication between peripheral equipment in the system, which has slower
transmission rates, and power management equipment.
B. Internet status indicator (2-pin LAN1_LED, LAN2_LED)
ese two 2-pin headers allow you to use the Gigabit internet indicator cable to connect
to the LAN status indicator. When this indicator ickers, it means that the internet is prop-
erly connected.
C. Chassis intrusion pin (2-pin CHASSIS)
is header is provided for host computer chassis with chassis intrusion detection designs.
In addition, it must also work with external detection equipment, such as a chassis intru-
sion detection sensor or a microswitch. When this function is activated, if any chassis
component movement occurs, the sensor will immediately detect it and send a signal to this
header, and the system will then record this chassis intrusion event. e default setting is
set to the CASEOPEN and GND pin; this function is o.
D. Locator LED (4-pin LOCATOR)
is header is for the locator switch and LED on the front panel.
E. System Fault LED (2-pin LOCATOR)
is header is for the Fault LED on the system.
