инструкция по эксплуатации станка JET, мод.JMD-2

11

Список деталей: фрезерный станок JMD-2

№

Артикул детали

Обозначение /

размер

Кол-

во

1

X10222

Taper shank B12

1

2 XN20222 Spindle oil enve

lop

circle

1

3

XN20208

Spindle

1

4

XN20224

Spindle lock sleeve II

1

5

XN20220

Fixup screw

1

6

XN20221

Fixup support

1

7

GB 6170-86 - M4

Nut M4

6

8

GB 818-85 - M3 x 6

Screw M3*6

9

9

GB 879-86 - 3 x 10

Spring pin 3*10

3

10

XN20213

Spindle box cover

(front)

1

11

GB 818-85-M4 x 14

Screw M4*14

4

12

XN20225

Small jacket

1

13

GD300

Display

1

14

GB 70-85 -16 x 50

Screw M6*50

1

15

XN20226

Spindle lock sleeve I

1

16

GB 819-85 - M3 x

12

Screw M3* 12

2

17

XN20217

Spindle sleeve Orien-

tation shaft

1

18 XN20201

Spindle box cover

(front)

1

19

GB 70-85 - M4 x 10

Screw M4*10

22

20

GB 894. 1 - 16

Spring check ring 16

1

21

XN20243

Check spring

1

22

X3C0253

Check spring cover

1

23

X3C0252

Left support flange

1

24 GB 278-89 -

1080905

Ball bearing

1080905

1

25

XN20215

Gasket III

1

26

GB 301-84 - 8105

Thrust ball bearing

1

27

XN20214

Gasket II

1

28

GB 858-88 - 24 x

34

Lock washer 24*34

1

29

GB 812-88 - M24 x

1.5

Round nut M24*1.5

1

30

GB 894. 1 - 35

Spring washer 35

1

31

XN20212

Spindle adjust pad

1

32

GB 278-89 -

1080907

Ballbearing 1080907

2

33

XN20211

Bearing set flange

1

34

XN20210

Spindle timing pulley

1

35

XN20209

Spindle box Cover

1

36

GB 70-85 - M5 x 40

Screw M5*40

4

37

XN20205

Flange

1

38

XN20206

Spindle top cover

1

39

HTDM5-320(64)

Timing belt 64

1

40

XN20202

Motor support plate

1

41

GB 70-85 - M5 x 12

Screw M5*12

8

42

GB 97. 1-85 - 5

Washer 5

6

43

GB 819 85 M6 x 12

Screw M6*12

1

44

XN20204

Washer IV

1

45

XN20203

Motor timing pulley

1

46

GB1096-79- 5 x 16

Key 5*16

1

47

500 W

Motor

1

48

GB 867-86 -2 x 8

Rivet 2*8

2

49

XN20223

Angle ruler

1

50

GB 923-88 - M10

Cap nut M10

8

№

Артикул детали

Обозначение /

размер

Кол-

во

51

GB 95-85 - 10

Washer 10

12

52

GB8-88 - M10 x 45

Square bolt Ml 0*45

4

53

XN20241

Left support flange I

1

54

GB 894. 1 - 20

Spring check ring 20

3

55

XN20240

Bevel wheel

1

56 XN20239

Bevel wheel fixup

steel sleeve

1

57

XN20245

Washer I

1

58

GB 118-86 - 9 x 20

Taper pin 6*20

2

59

GB 70-85 - M5 x 20

Screw M5*20

4

60

XN20229

Set sleeve

1

61

X3C023500

Control shaft assem-

bly

3

62

GB2089-80

0.7x6x25

Compress spring

0.7*6*25

3

63

X3C023600

Control shaft assem-

bly

3

64

GB 896 - 4

Spring wahser 4

3

65

Ф4x2

Small magnetism

block

1

66 X3C0237 Assistant small han-

dle

1

67

GB 119-86 - A 3 x

14

Round pin 3*14

1

68

X3C0238

Worm wheel lock

handle

1

69

XN20237

Gear shaft adjust pad

1

70

XN20238

Big handle seat

1

71

XN2023500

Guide electricity ring

assembly

1

72

XN20231

Worm support box

body

1

73

X3C0234

Guide electricity bar

1

74

X3C0243

Fixup support

1

75

GB 819-85 - M3 x 6

Screw M3*6

2

76

GB 923-88 - M8

Cap nut M8

1

77

GB 97. 1-85 - 8

Washer 8

1

78

XN20234

Worm gear handle

1

79

XN20233

Worm flange

1

80

XN20232

Worm adjust pad

1

81

XN20230

Worm

1

82

GM 1096-79 4 x

8

key 4*8

3

83

XN20236

Lock small shafl

1

84

XN20242

Gear shaft

1

85

GB308—89 - 8

Steel ball 8

3

86

XN20244

Motherboard

1

87

GB 818-85 - M4 x 8

Screw M4*8

6

88

XN20219

Sleeve limited wash-

er

1

89

XN20216

Spindle sleeve

1

90

XN20218

Spindle sleeve enve-

lop oil circle

1

91

GB/T 297-94 -

32906

Prick ball bearing

32906

1

92

XN20207

Suspend lock shank

1

93

XN21904

Rubber pad

1

94

SB-26

Protect line sleeve

3

95

XN2190300

Tray assembly

1
