ASRock EPC621D6U-2T [10/87] English
![ASRock EPC621D6U-2T [10/87] English](/views2/1694415/page10/bga.png)
4 5
English
IPMB Header 1
Buzzer 1
Fan Header 6 Fans x (6-pin) (CPU/4Front/Rear)
ATX Power 1 (24-pin) + 1 (8-pin)
USB 3.0 Header 1 (supports 2 USB 3.0 ports)
USB 2.0 Header 1 (supports 2 USB 2.0 ports)
Type A USB 3.0 1
SATA DOM 1 (SSATA_5, shared with M.2)
COM Port
Header
1
80 debug port
LED
1
Front Panel 1 (RST, PWRBTN, HDDLED, PWRLED)
Speaker 1 (4pin)
TR1 1
SGPIO 1
Smbus from
BMC
1
PWR_SMB 1
M.2 1 (2230/2242/2260/2280), supports PCIE3.0(X4)/SATA3 (SATA
type is shared with SSATA_5)
NMI Button 1 (Header)
ME/SPS
recovery
1
ClearCMOS 1 (short pin)
OH/FanFail
LED
6 (only Fan Fail LED)
System BIOS
BIOS Ty pe 256Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- SystemTemperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
