ASRock EP2C622D16-2T [8/98] Specifications
![ASRock EP2C622D16-2T [8/98] Specifications](/views2/1694453/page8/bg8.png)
2 3
English
1.2 Specications
EP2C622D16-2T
MB Physical Status
Form Factor SSI EEB
Dimension 12'' x 13'' (30.5 cm x 33.0 cm)
Processor System
CPU Supports 2
nd
Gen. Intel® Xeon® Scalable Processors / Intel® Xeon®
Scalable Processors
Socket Dual Socket LGA-3647
Chipset Intel® C622
System Memory
Capacity 16 x 288-pin DDR4 DIMM slots
- Support up to 64GB DDR4 R DIMM/LR DIMM/NVDIMM
Type - Six Channel memory technology
- Support DDR4 2666/2400/2133 R DIMM/LR DIMM /
NVDIMM
Voltage 1.2V
DIMM Size per
DIMM
R DIMM/LR DIMM/NVDIMM: 64GB, 32GB, 16GB, 8GB, 4GB
DIMM
Frequency
R DIMM/LR DIMM/NVDIMM: 2666/2400/2133 MHz
Expansion Slot
PCIe x16 SLOT2: Gen3 x16 link (CPU2)
SLOT3: Gen3 x16 link (CPU2)
SLOT4: Gen3 x16 link (CPU2)
SLOT6: Gen3 x16 link (CPU1)
Storage
SATA
Controller
Intel® C622 : 14 x SATA3 (including 2 x SATA DOM ports
(SSATA_4 / SSATA_5), 1 x Mini-SAS HD 8i Connector
(MINISAS_1), 2 x SATA ports (SATA_0, SATA_1), and 2 x M.2
ports
RAID Support Mini-SAS HD 8i Connector (MINISAS_1): 0, 1, 5, 10
2 x SATA Ports (SATA_0, SATA_1): 0, 1
2 x M.2: 0, 1
M.2 2 (2230/2242/2260/2280/22110, PCIE(x4)/SATA3)
U.2 from
OCulink or
Slimline
2 (Slimline x8 from CPU1, Oculink x4 from CPU1)
Ethernet
Interface Gigabit LAN 10000/1000 /100 Mbps
