ASRock D2143D8UM [10/83] English
![ASRock D2143D8UM [10/83] English](/views2/1694489/page10/bga.png)
4 5
English
Virtual
- VMWare ESXi 6.5 u1
- Citrix XenServer 7.2
- Win hyper-V Server 2016
*Please refer to our website for the latest OS support list.
*On Ubuntu 16.04 (64bit) system, Intel Raid mode only supports UEFI BOOT.
*Ubuntu 18.04 (64bit) does not support Intel Raid mode (AHCI only).
Environment
Temperature Operation temperature: 10°C ~ 35°C /
Non operation temperature: -40°C ~ 70°C
*Install a CPU Fan when the airow through the heatsink is below 2CFM.
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.
