8 Таблицы производительности

8 - 1 Таблицы холодопроизводительности

UATYQ450CY1

AFR (CFM)

EWB EDB

Outdoor temperature

19°C 25°C 30°C 35°C 40°C 46°C

TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI

4520

16°C

21°C 44.03 29.82 10.49 42.37 29.06 11.10 41.41 28.82 11.95 39.46 27.89 12.68 36.67 26.40 13.77 34.12 25.22 15.25

24°C 44.20 34.76 10.50 42.53 33.98 11.11 41.57 33.82 11.96 39.64 32.93 12.69 36.97 31.10 13.79 34.60 29.48 15.28

28°C 45.14 42.60 10.55 43.59 41.45 11.17 42.78 41.04 12.03 41.00 39.63 12.77 38.48 37.56 13.89 36.28 35.59 15.40

30°C 46.31 46.31 10.66 44.87 44.87 11.30 43.33 43.33 12.18 41.69 41.69 12.94 39.13 39.13 14.06 36.98 36.98 15.58

19°C

24°C 48.15 28.14 10.72 46.29 27.41 11.34 45.27 27.20 12.20 43.16 26.39 12.93 40.18 25.04 14.03 37.46 23.96 15.50

27°C 48.28 34.64 10.73 46.44 33.87 11.35 45.40 33.74 12.21 43.31 32.87 12.94 40.32 31.33 14.04 37.62 30.22 15.52

30°C 48.53 40.62 10.74 46.88 39.53 11.37 46.01 39.13 12.24 44.06 37.85 12.99 41.23 35.81 14.10 38.76 34.19 15.60

33°C 49.45 49.45 10.81 47.32 47.32 11.45 47.63 47.63 12.35 45.88 45.88 13.11 41.83 41.83 14.24 40.04 40.04 15.76

22°C

27°C 52.24 27.61 10.98 50.49 27.04 11.61 49.38 26.84 12.48 47.12 26.05 13.21 43.90 24.75 14.31 41.05 23.79 15.79

30°C 52.63 34.34 10.98 50.61 33.58 11.61 49.48 33.46 12.49 47.25 32.63 13.22 44.01 31.13 14.32 41.16 30.10 15.80

33°C 52.76 40.56 10.99 50.74 39.79 11.62 49.60 39.76 12.49 47.39 38.93 13.23 44.33 36.87 14.35 41.76 35.24 15.84

36°C 52.99 45.05 11.03 51.17 43.88 11.68 50.55 43.79 12.57 48.52 42.50 13.32 45.70 40.55 14.44 43.22 38.87 15.96

5650

16°C

21°C 45.61 31.21 10.58 43.80 30.39 11.19 42.77 30.13 12.04 40.72 29.21 12.76 37.80 27.69 13.86 35.12 26.50 15.33

24°C 45.90 38.49 10.60 44.24 37.37 11.21 43.33 36.89 12.07 41.41 35.59 12.81 38.59 33.52 13.91 36.09 31.82 15.39

28°C 47.64 44.93 10.68 46.08 43.68 11.32 45.29 43.15 12.19 43.48 41.63 12.94 40.74 39.20 14.06 38.36 37.10 15.57

30°C 49.38 49.38 10.84 47.75 47.75 11.48 46.05 46.05 12.37 44.27 44.27 13.13 41.05 41.05 14.26 38.76 38.76 15.76

19°C

24°C 49.76 31.07 10.82 47.79 30.25 11.44 46.67 30.00 12.29 44.47 29.11 13.02 41.33 27.61 14.12 38.49 26.47 15.59

27°C 50.00 38.53 10.83 48.04 37.70 11.45 46.92 37.59 12.31 44.72 36.67 13.04 41.71 34.75 14.14 39.07 33.00 15.63

30°C 51.03 44.13 10.88 49.19 42.92 11.52 48.22 42.50 12.39 46.18 41.17 13.13 43.26 38.90 14.26 40.85 36.92 15.76

33°C 52.12 52.12 11.00 50.46 50.46 11.66 48.70 48.70 12.56 46.82 46.82 13.32 43.95 43.95 14.46 41.59 41.59 15.97

22°C

27°C 54.15 30.65 11.08 52.02 29.91 11.71 50.82 29.74 12.58 48.46 28.87 13.31 45.08 27.41 14.41 42.08 26.32 15.88

30°C 54.34 38.29 11.09 52.22 37.49 11.72 51.02 37.40 12.59 48.67 36.51 13.33 45.29 34.88 14.43 42.33 33.78 15.90

33°C 54.72 45.39 11.11 52.77 44.15 11.75 51.75 43.71 12.64 49.56 42.32 13.39 46.32 40.07 14.51 43.60 38.35 16.00

36°C 55.74 48.99 11.19 53.78 48.01 11.84 52.42 47.14 12.75 50.49 45.64 13.52 46.96 42.65 14.67 44.05 40.21 16.20

6780

16°C

21°C 46.70 33.59 10.64 44.83 32.74 11.25 43.73 32.48 12.10 41.63 31.51 12.82 38.61 29.89 13.91 35.86 28.64 15.39

24°C 47.52 40.82 10.69 45.72 39.59 11.30 44.74 39.10 12.16 42.73 37.73 12.90 39.81 35.57 13.99 37.35 33.59 15.49

28°C 49.82 46.99 10.81 48.08 45.57 11.44 47.27 45.04 12.33 45.32 43.40 13.07 42.42 40.82 14.19 39.90 38.59 15.70

30°C 51.16 51.16 10.98 49.43 49.43 11.63 47.62 47.62 12.52 45.72 45.72 13.28 43.03 43.03 14.40 40.15 40.15 15.91

19°C

24°C 50.91 33.49 10.88 48.86 32.64 11.50 47.65 32.40 12.36 45.35 31.45 13.09 42.15 29.89 14.18 39.25 28.72 15.65

27°C 51.25 41.96 10.90 49.26 40.97 11.53 48.24 40.47 12.40 46.07 39.04 13.14 42.96 36.82 14.24 40.24 35.02 15.72

30°C 52.80 46.35 10.99 51.00 45.18 11.63 50.14 44.64 12.52 48.13 43.07 13.28 45.11 40.57 14.40 42.55 38.45 15.91

33°C 54.03 54.03 11.16 52.27 52.27 11.82 50.90 50.90 12.72 48.94 48.94 13.49 45.90 45.90 14.62 42.91 42.91 16.14

22°C

27°C 55.30 33.21 11.15 53.11 32.38 11.78 51.83 32.16 12.65 49.35 31.24 13.38 45.93 29.72 14.48 42.88 28.61 15.95

30°C 55.62 41.78 11.17 53.40 40.93 11.80 52.12 40.86 12.67 49.67 39.93 13.41 46.29 38.09 14.51 43.44 36.28 15.99

33°C 56.66 48.41 11.22 54.57 47.07 11.87 53.46 46.64 12.76 51.20 45.21 13.51 47.83 42.80 14.63 45.22 40.67 16.14

36°C 57.59 50.76 11.35 55.14 48.85 12.02 54.34 48.38 12.94 52.28 46.78 13.71 48.58 43.69 14.85 46.00 41.58 16.38

NOTES - ANMERKUNGEN - ƴƩƮƧƫƺƴƧƫƴ - NOTAS - REMARQUES - NOTE - OPMERKINGEN - ǽǾǶǺǳȅǮǻǶȍ - NOTLAR

1. Ratings shown are gross capacities which do not include a deduction for indoor fan motor heat. - Die Nennwerte sind Bruttoleistungen, die keine Abzüge für die Motorwärme der

Innenventilatoren enthalten. - ȅȚ ĲȚȝȑȢ ʌȠȣ ĮȞĮĳȑȡȠȞĲĮȚ ĮȞĲȚʌȡȠıȦʌİȪȠȣȞ ȝȚțĲȒ ĮʌȩįȠıȘ, ȤȦȡȓȢ țȐʌȠȚĮ ȝȚțȡȒ ĮʌȩțȜȚıȘ ʌȠȣ ĮȞĲȚıĲȠȚȤİȓ ıĲȘ șȑȡȝĮȞıȘ ĲȠȣ țȚȞȘĲȒȡĮ ĲȠȣ ĮȞİȝȚıĲȒȡĮ ĲȘȢ

İıȦĲİȡȚțȒȢ ȝȠȞȐįĮȢ. - Los valores indicados son capacidades brutas a las que no se ha restado el valor correspondiente al calor del motor del ventilador interior. - Les valeurs nominales

indiquées correspondent à des puissances brutes qui n’incluent aucune déduction pour la chaleur du moteur de ventilateur de l’unité intérieure. - I valori indicati si riferiscono alle capacità

lorde e non comprendono la riduzione per l’apporto di calore generato dal motore del ventilatore dell’unità interna. - De weergegeven cijfers zijn brutocapaciteiten excl. reductiefactor

voor warmte afgegeven door de binnenventilatormotor. - ɍɤɚɡɚɧɧɵɟ ɧɨɦɢɧɚɥɶɧɵɟ ɡɧɚɱɟɧɢɹ ɹɜɥɹɸɬɫɹ ɨɛɳɢɦɢ, ɬ.ɟ. ɧɟ ɭɱɢɬɵɜɚɸɬ ɧɚɝɪɟɜɚɧɢɟ ɨɬ ɞɜɢɝɚɬɟɥɹ ɜɧɭɬɪɟɧɧɟɝɨ

ɜɟɧɬɢɥɹɬɨɪɚ. - Gösterilen de÷erler, iç ünite fan motoru sıcaklı÷ının dikkate alınmadı÷ı brüt kapasite de÷erleridir.

shows nominal capacities. - stellt Nennleistungen dar. - ȣʌȠįİȚțȞȪİȚ ȠȞȠȝĮıĲȚțȑȢ ĲȚȝȑȢ ĮʌȩįȠıȘȢ.- indica capacidades nominales.- indique les

puissances nominales.-

mostra le capacità nominali.- geeft nominale capaciteiten weer.- ɩɨɤɚɡɵɜɚɟɬ ɧɨɦɢɧɚɥɶɧɵɟ ɡɧɚɱɟɧɢɹ ɦɨɳɧɨɫɬɢ.- nominal

kapasite de÷erlerini gösterir.

3. Direct interpolation is permissible. Do not extrapolate. - Direkte Interpolation ist zulässig. Extrapolieren ist nicht zulässig. - ǼʌȚĲȡȑʌİĲĮȚ Ș ĮʌİȣșİȓĮȢ ʌĮȡİȝȕȠȜȒ. ǵȤȚ ȩȝȦȢ Ș ʌĮȡİțȕȠȜȒ.

- Se permite la interpolación directa. Sin embargo, no extrapole. - Interpolation directe autorisée. Ne pas extrapoler. - È consentita l’interpolazione diretta. Non è tuttavia permessa

l’estrapolazione. - Directe interpolatie is toegestaan. Extrapoleer niet. - Ⱦɨɩɭɫɤɚɟɬɫɹ ɩɪɹɦɚɹ ɢɧɬɟɪɩɨɥɹɰɢɹ. ɗɤɫɬɪɚɩɨɥɹɰɢɹ ɧɟ ɞɨɩɭɫɤɚɟɬɫɹ. - Do÷rudan interpolasyon yapılmasına

izin verilir. Ekstrapolasyon yapmayın.

4. Unit is able to operate at ambient from 0°C to 46°C without pressure trip. - Gerät kann bei Umgebungstemperaturen von 0°C bis 46°C ohne Druckabfall betrieben werden. - Ǿ ȝȠȞȐįĮ ȑȤİȚ

ĲȘ įȣȞĮĲȩĲȘĲĮ ȞĮ ȜİȚĲȠȣȡȖİȓ ıİ șİȡȝȠțȡĮıȓĮ ʌİȡȚȕȐȜȜȠȞĲȠȢ Įʌȩ 0°C ȑȦȢ 46°C ȤȦȡȓȢ ʌĲȫıȘ ʌȓİıȘȢ. - La unidad puede funcionar con temperaturas ambiente de entre 0 y 46°C sin cortes

por presión. - L’unité est en mesure de fonctionner par température extérieure comprise entre 0 °C et 46 °C sans déclenchement pression. - L’unità è in grado di funzionare con temperature

esterne comprese tra 0° e 46° senza cali di pressione. - De unit kan werken bij omgevingstemperaturen van 0°C tot 46°C zonder drukuitschakeling. - Ȼɥɨɤ ɦɨɠɟɬ ɪɚɛɨɬɚɬɶ ɩɪɢ

ɬɟɦɩɟɪɚɬɭɪɟ ɨɤɪɭɠɚɸɳɟɣ ɫɪɟɞɵ ɨɬ 0 ɞɨ 46°ɋ ɛɟɡ ɨɬɤɥɸɱɟɧɢɹ, ɜɵɡɵɜɚɟɦɨɝɨ ɞɚɜɥɟɧɢɟɦ. - Ünite, 0°C ila 46°C ortam sıcaklı÷ında basınç problemi olmadan çalıúabilir.

AFR: Air ﬂow rate - Luftdurchsatz - ȉĮȤȪĲȘĲĮ ȡȠȒȢ ĮȑȡĮ - Caudal de aire - Débit d’air - Portata d’aria - Luchtdebiet - ɋɤɨɪɨɫɬɶ ɜɨɡɞɭɲɧɨɝɨ ɩɨɬɨɤɚ - Hava akıú hızı (CFM)

EWB: Entering Wet Bulb Temp. - Eingangs-Feuchttemp. - ǼȓıȠįȠȢ ıİ șİȡȝ. ȣȖȡȠȪ ȕȠȜȕȠȪ - Temperatura de bulbo húmedo de entrada - Température d’entrée du réservoir humide - Temp.

bulbo umido in entrata - Temperatuur ingaand natte bol - Ɍɟɦɩɟɪɚɬɭɪɚ ɧɚ ɜɯɨɞɟ ɜɥɚɠɧɨɝɨ ɬɟɪɦɨɦɟɬɪɚ. - Giriú ıslak hazne sıcaklı÷ı (°C)

EDB: Entering Dry Bulb Temp. - Eingangs-Trockentemp. - ǼȓıȠįȠȢ ıİ șİȡȝ. ȜȣȤȞȓĮȢ ĮĳȪȖȡĮȞıȘȢ - Temperatura de bulbo seco de entrada - Température d’entrée du réservoir sec - Temp.

bulbo secco in entrata - Temperatuur ingaand droge bol - Ɍɟɦɩɟɪɚɬɭɪɟ ɧɚ ɜɯɨɞɟ ɫɭɯɨɝɨ ɬɟɪɦɨɦɟɬɪɚ. - Giri

ú kuru hazne sıcaklı÷ı (°C)

TC: Total Cooling Capacity - Gesamte Kühlleistung - ȈȣȞȠȜȚțȒ ĮʌȩįȠıȘ ȥȪȟȘȢ - Capacidad de refrigeración total - Puissance totale de refroidissement - Capacità di raffreddamento totale -

Totaal koelvermogen - Ɉɛɳɚɹ ɨɯɥɚɠɞɚɸɳɚɹ ɫɩɨɫɨɛɧɨɫɬɶ - Toplam so÷utma kapasitesi (kW)

SHC: Sensible Heat Capacity - Sensible Wärmekapazität - ǹʌȩįȠıȘ ĮȚıșȘĲȒȢ șȑȡȝĮȞıȘȢ - Capacidad de calor sensible - Puissance caloriﬁque sensible - Capacità termica sensibile -

Voelbaar verwarmingsvermogen - ɉɪɨɢɡɜɨɞɢɬɟɥɶɧɨɫɬɶ ɩɨ ɫɭɯɨɦɭ ɬɟɩɥɭ - Hissedilebilir ısı kapasitesi (kW)

PI: Power Input - Leistungsaufnahme - ǼȓıȠįȠȢ ȚıȤȪȠȢ - Consumo - Puissance absorbée - Potenza assorbita - Vermogeninput - ɉɨɬɪɟɛɥɹɟɦɚɹ ɦɨɳɧɨɫɬɶ - Güç giriúi

REMARK - BEMERKUNGEN - ƲƣƳƣƵƩƳƝƴƧƫƴ - OBSERVACIONES - REMARQUES - NOTE - OPMERKINGEN - ǵǮǺǳȅǮǻǶȍ - DÜûÜNCELER
