2. GuidetoRAIDCongurations

2.1 Introduction of RAID

ThismotherboardadoptsIntelsouthbridgechipsetthatinte-

gratesRAIDcontrollersupportingRAID0/RAID1/IntelRapid

Storage/RAID10/RAID5functionwithfourindependentSe-

rialATA(SATA)channels.Thissectionwillintroducethebasic

knowledgeofRAID,andtheguidetocongureRAID0/RAID

1/IntelRapidStorage/RAID10/RAID5settings.

RAID

Theterm“RAID”standsfor“RedundantArrayofIndependent

Disks”,whichisamethodcombiningtwoormoreharddisk

drivesintoonelogicalunit.Foroptimalperformance,please

installidenticaldrivesofthesamemodelandcapacitywhen

creatingaRAIDset.

RAID 0 (Data Striping)

RAID0iscalleddatastripingthatoptimizestwo

identicalharddiskdrivestoreadandwritedata

inparallel,interleavedstacks.Itwillimprovedata

accessandstoragesinceitwilldoublethedata

transferrateofasinglediskalonewhilethetwo

harddisksperformthesameworkasasingle

drivebutatasustaineddatatransferrate.

WARNING!!

AlthoughRAID0functioncanimprovetheaccessperformance,

it does not provide any fault tolerance. Hot-Plug any HDDs of

theRAID0Diskwillcausedatadamageordataloss.

RAID 1 (Data Mirroring)

RAID1iscalleddatamirroringthatcopiesand

maintainsanidenticalimageofdatafromone

drivetoaseconddrive.Itprovidesdataprotection

andincreasesfaulttolerancetotheentiresystem

sincethediskarraymanagementsoftwarewill

directallapplicationstothesurvivingdriveasit
