EP2C612D16NM Series
PB 1
English
Chapter 1 Introduction
ank you for purchasing ASRock Rack EP2C612D16NM / EP2C612D16NM-8R /
EP2C612D16NM-2T / EP2C612D16NM-2T8R motherboard, a reliable motherboard
produced under ASRock Rack’s consistently stringent quality control. It delivers
excellent performance with robust design conforming to ASRock Rack’s commitment
to quality and endurance.
In this manual, chapter 1 and 2 contains introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration
guide to BIOS setup and information of the Support CD.
1.1 Package Contents
•
ASRock Rack EP2C612D16NM / EP2C612D16NM-8R / EP2C612D16NM-2T /
EP2C612D16NM-2T8R Motherboard
(SSI EEB Form Factor: 12.0-in x 13.0-in, 30.5 cm x 33.0 cm)
•
4 x SATA3 Cables (50cm)
•
2 x SATA3 Cables (6G) (60cm)
•
2 x Mini SAS HD to 4 SAS/SATA Cables (12G)
(for EP2C612NM-8R / EP2C612NM-2T8R only)
•
2 x I/O Shields (1 for M599, 1 for M350/M540)
•
Support CD
•
User Manual
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/
