EP2C612D8 / EP2C612D8-8R / EP2C612D8-2T8R
Quick Installation Guide
www.asrockrack.com
1G For EP2C612D8-8R / EP2C612D8
Speed LED Activity / Link LED
Status Description Status Description
O 10Mbps connection or
no link
O No link
Yellow 100Mbps connection Blinking Green Data Activity
Green 1Gbps connection On Link
10G For EP2C612D8-2T8R
Speed LED Activity / Link LED
Status Description Status Description
O 100Mbps connection or
no link
O No link
Yellow 1Gbps connection Blinking Green Data Activity
Green 10Gbps connection On Link
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10M bps connection or no
link
Blinking Yellow Data Activity Yellow 100M bps connection
On Link Green 1G bps connection
8 LAN Port LED Indications
Recommended Memory Congurations
ACT/LINK LED
SPEED LED
LAN Port
5
7
9
6
1
2
3
Open the socket levers and the
CPU socket cover.
Install the processor and close
the socket cover.
Close the socket levers. Remove
the CPU protection cap.
Install the CPU Fan and Heatsink
CPU_
FAN
1
2
Apply the thermal grease. Install the
CPU fan and heatsink and secure
the screws.
Connect the CPU fan to the CPU
FAN connector.
Install the Memory
Install the Power Cables
1
2
3
Unlock a DIMM slot by
pressing the module clips
outward.
Insert the memory module. Lock the clips.
11
Install the PCIE Card
1
Remove the bracket facing the slot that
you intend to use. Keep the screw for
later use.
2
Align the card connector with the
slot and press firmly until the card is
completely seated on the slot.
Fasten the card to the chassis with the
screw.
3
A
B
B
A
A
B
A
B
A
B
IPMI LAN Port
1G/10G LAN Port
System Panel Header Auxiliary Panel Header
12
Headers
GND
RESET#
PWRBTN#
PLED-
PLED+
GND
HDLED-
HDLED+
1
GND
10
Install the Processor
4
8
1
5
+12V2
GND
4
8
1
5
+12V2
GND
ACT/LINK LED
SPEED LED
LAN Port
A single memory module should be installed in the BLUE socket.
If you install only one CPU (CPU1) on the motherboard, make sure to install DIMMs into DDR4_A,
DDR4_B, DDR4_C, or DDR4_D slot(s).
1 CPU Conguration
CPU1
A B C D
1 DIMM
#
2 DIMMS
# #
4 DIMMS
# # # #
*e # mark indicates the slot is populated.
2 CPU Conguration
CPU1 CPU2
A B C D E F G H
1 DIMM
#
2 DIMMS
# #
4 DIMMS
# # # #
8 DIMMS
# # # # # # # #
GND
SMB_CLK
SMB_Alert
CASEOPEN
1
SMB_DATA
+3VSB
LAN1_LINK
LED_PWR
LAN2_LINK
LED_PWR
+5VSB
GND
GND
LOCATORLED1+
LOCATORLED1-
LOCATORBTN#
LOCATORLED2+
LOCATORLED2-
A
B
C
D
1
3V
3V
GND
GND
5V
5V
GND
PWROK_PS
5VSB
12V
12V
3V
3V
-12V
GND
PSON#
GND
GND
GND
5V
5V
5V
GND
N/A
12
24 13
We recommend using the CPU Installation tool to avoid CPU pin-bent problem.
