E3C246D4M-4L / E3C242D4M-4L
10 11
English
No. Description
1 BMC SMBus Header (BMC_SMB_1)
2 ATX 12V Power Connector (ATX12V1)
3 Intelligent Platform Management Bus Header (IPMB_1)
4 ME Recovery Jumper (ME_RECOVERY1)
5 PWM Conguration Header (PWM_CFG1)
6 Rear Fan Connector (REAR_FAN1)
7 PSU SMBus (PSU_SMB1)
8 ATX Power Connector (ATXPWR1)
9 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)
10 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)
11 CPU Fan Connector (CPU_FAN1)
12 Front Fan Connector (FRNT_FAN1)
13 Front Fan Connector (FRNT_FAN2)
14 Front Fan Connector (FRNT_FAN3)
15 SATA3 DOM Connector (SATA_0), Red
16 SATA3 Connector (SATA_1)
17 SATA SGPIO Connector (SATA_SGPIO1)
18 SATA SGPIO Connector (SATA_SGPIO2)
19 SATA DOM Power Jumper (SATAPWR1)
20 CPU PECI Mode Jumper (PECI1)
21 SATA DOM Power Header (SATA_PWR1)
22 Front Fan Connector (FRNT_FAN4)
23 SATA3 Connector (SATA_2)
24 SATA3 Connector (SATA_3)
25 SATA3 Connector (SATA_4)
26 SATA3 Connector (SATA_5)
27 Chassis Speaker Header (SPEAKER1)
28 System Panel Header (PANEL1)
29 Auxiliary Panel Header (AUX_PANEL1)
30 USB 2.0 Header (USB_1_2)
31 Flash Descriptor Security Override Jumper (SEC_OR1)
32 USB 2.0 Header (USB_3_4)
33 Vertical Type A USB 3.1 Gen1 Connector (USB31_7)
