Graphics
Controller ASPEED AST2300
VRAM DDR3 16MB
Output
Supports D-Sub with max. resolution up to
1920x1200 @ 60Hz
Ethernet
Interface Gigabit LAN 10/100/1000 Mb/s
IPMI
dedicated
GLAN
Realtek RTL8211E
LAN
Controller
EP2C606-4L / EP2C602-4L
4 x Intel
®
82574L
EP2C602
2 x Intel
®
82574L
Rear Panel
I/O
Lan port
(RJ45)
EP2C606-4L / EP2C602-4L
4 + 1 (for IPMI)
EP2C602
2 + 1 (for IPMI)
PS/2 KB/
mouse
2
VGA port D-sub x 1
USB port 2 x USB 2.0
Serial port 1 (COM1)
Internal
connector
COM port
header
1 (COM2)
Auxiliary
panel header
1 (include chassis intrusion , location button
& LED, front LAN LED)
TPM header 1
IPMB header 1
Buzzer 1
Fan header
"8 x 4-pin" or "6 x 4-pin and 2 x 3-pin"
*CPU fan header have 3-pin and 4-pin, only
one of them can be used at a time.
ATX power 1 (24-pin) + 2(8-pin)
USB header 2 (each support 2 USB 2.0)
Type A USB
2.0 port
1
