1.2 Specications
EP2C606-4L/D16 / EP2C602-4L/D16 / EP2C602/D16:
Physical
Status
Form Factor SSI EEB
Dimension 12'' x 13'' (30.5 cm x 33 cm)
Processor
System
CPU
- Supports Intel
®
Xeon processor E5-
1600*/2600/4600 & v2 series
* E5-1400 & E5-1600 support single socket.
Socket Dual Socket R (LGA2011)
Power Phase 6 +1 Power Phase Design
Chipset
EP2C606-4L/D16
Intel
®
C606
EP2C602-4L/D16 / EP2C602/D16
Intel
®
C602
BIOS BIOS type 64Mb AMI UEFI Legal BIOS
System
Memory
Capacity
- 16x 240-pin DDR3 DIMM slots
- Support up to 512GB DDR3 R/LR DIMM ;
128GB ECC/non-ECC unbuffered UDIMM
Type
- Quad Channel DDR3 memory technology
- Supports DDR3 1866/1600/1333/1066
R/LR ECC and UDIMM
Voltage - 1.5V, 1.35V
Expansion
Slot
PCIe 3.0 x 16
4 slots (2 x16, 1 x16/x8, 1 x8/x0)
PCIe 3.0 x 4
1 slots
PCI
1 slots
Storage
SATA/SAS
controller
EP2C606-4L/D16
2 x SATA3 6.0 Gb/s , 4 x SATA2 3.0 Gb/s ,
8xSATA2/SAS 3Gb/s
EP2C602-4L/D16 / EP2C602/D16
2 x SATA3 6.0 Gb/s , 8 x SATA2 3.0 Gb/s
Additional
SATA
controller
Marvell 9230 : 4 x SATA3 6.0 Gb/s
BMC Controller ASPEED AST2300
