![Daikin UAT180AMY1 [7/43] Specifications](/img/pdf.png)
Daikin UAT180AMY1 [7/43] Specifications
![Daikin UAT180AMY1 [7/43] Specifications](/views2/1694833/page7/bg7.png)
• Cooling only • R-22 • UAT-AMY1
1
2
• Rooftops • Cooling only
3
2 Specifications
Dimensions Unit Height mm 1,200 1,735 1,735 1,974 1,974
Width mm 1,990 2,250 2,250 2,252 2,252
Depth mm 1,670 2,800 2,800 3,180 3,180
Packing Height mm 1,320 1,900 1,900 2,150 2,150
Width mm 2,100 2,250 2,250 2,300 2,300
Depth mm 1,810 2,900 2,900 3,250 3,250
Condensor Weight Unit kg 765 1,200 1,350 1,510 1,600
Heat
Exchanger
Dimensions Face
Area
m² 2 x 1.25 2 x 3.01 2 x 3.01 3.50 3.50
Condensor Air Flow Rate Cooling m³/min 320 566 566 566 566
Motor Output W 550 1,500 1,500 3,465 3,465
Compressor Quantity 2 2 2 2 2
Compressor Motor Type Scroll type
Operation
Range
Cooling Min °CDB 20°C
Max °CDB 54°C
Condensor Sound Level
(nominal)
Sound
power
dBA7074748080
Refrigerant Type R-22
Charge kg 2 x 5.9 2 x 10.5 2 x 10.4 16.5 & 19.5 2 x 19.5
Control Capillary tube Thermal expansion
valve
Thermal expansion
valve
Thermal expansion
valve
Thermal expansion
valve
Safety Devices High pressure switch
Phase sequencer
Discharge thermostat setting
Notes All specifications are subjected to change by the manufacturer without prior notice.
All units are being tested and comply to ISO5151.
Nominal cooling and heating capacity are based on the following conditions: cooling -27°CDB/19°CWB indoor and
35°CDB/24°CWB outdoor, heating -20°CDB indoor and 7°CDB/6°CWB outdoor.
Sound pressure levels are according to JIS B 8615 standard. Position of the measurement is 1m in front and 1m below
the unit.
Designation based on cooling cycle.
2-3 ELECTRICAL SPECIFICATIONS UAT180AMY1 UAT240AMY1 UAT280AMY1 UAT320AMY1 UAT450AMY1
Power Supply Name Y1
Phase 3~
Frequency Hz 50 50 50 50 50
Voltage V 380-415
Current Nominal
running current
(RLA)
Cooling
(A)
A 10.4 15.4 18.2 22.1 29.0
2-3 ELECTRICAL SPECIFICATIONS UAT560AMY1 UAT700AMY1 UAT850AMY1 UATC10AMY1 UATC12AMY1
Power Supply Name Y1
Phase 3~
Frequency Hz 50 50 50 50 50
Voltage V 380-415
Current Nominal
running current
(RLA)
Cooling
(A)
A 35.7 49.6 62.7 67.2 72.8
2-2 TECHNICAL SPECIFICATIONS UAT560AMY1 UAT700AMY1 UAT850AMY1 UATC10AMY1 UATC12AMY1
