ASRock M540R Инструкция онлайн [10/12] 540464
1 QSFP+ 40Gb/s (LAN1)
2 QSFP+ 40Gb/s (LAN2)
1
2
MCX3
•
1 x Mezzanine Card
•
4 x Screws
•
4 x Standos
•
4 x Nuts
•
1 x Support CD
•
1 x Quick Installation Guide
Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these head-
ers and connectors. Placing jumper caps over the headers and connectors will cause permanent
damage to the motherboard.
Front LAN LED Connector
(LAN_ LED1)
1
LAN1_LINK
LED_PWR
LED_PWR
LAN2_LINK
is 4-pin connector is used for
the front LAN status indicator.
LAN Port LED Indications
Package Contents
LAN2
(4.3in)109.40mm
(2.7in)68.00mm
(0.5in)13.80mm
LAN1
Layout
Onboard Header
Activity/LinkLED
Status Description
O No Link
Blinking Data Activity
PhysicalConnectionLED
Status Description
On Connected
O Disconnected
ACT/LINK
LED
PHYSICAL
CONNECTION
LED
LAN Port
