MECHANICAL SPECIFICATION
Case No.994D Unit:mm
200W Constant Current Mode LED Driver
HLG-185H-C series
File Name:HLG-185H-C-SPEC 2019-05-09
※ B-Type
※ A-Type
• : Max. Case Temperature
tc
tc
tc
300 20±
FG (Green/Yellow)
228
204
AC/L(Brown)
AC/N(Blue)
12
9.6
9.49.4 34.2
68
300 20±
38.8
102
34
Io
ADJ.
ψ×4.2 4PL
300 20±
38.8
228
204
12
9.6
9.49.4 34.2
68
300 20±
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
102
34
ψ×4.2 4PL
• : Max. Case Temperature
tc
SJOW 17AWG&H05RN-F 1.0mm x3C²
SJOW 17AWG&H05RN-F 1.0mm x3C²
SJOW 17AWG&H05RN-F 1.0mm x2C²
+V(Brown)
-V(Blue)
DIM-(Black)
DIM+(Gray)
+V(Brown)
-V(Blue)
SOOW 17AWG&H07RN-F 1.0mm x2C²
SJOW 17AWG&H05RN-F 1.0mm x2C(for others)²
(for HLG-185H-C500)
SOOW 17AWG&H07RN-F 1.0mm x2C²
SJOW 17AWG&H05RN-F 1.0mm x2C(for others)²
(for HLG-185H-C500)
